Image similar
Nexperia TVS diode PESD15VS2UT,215 SOT 23 17.6 V 160 W
Product type
TVS diode
Enclosure
SOT 23
Reverse voltage U(R)
15 V
Terminal voltage U(CL)
40 V
Power (max) P(TOT)
160 W
Datasheet (PDF)
EAN:
Part number:
Item no:
Number
Minimum order quantity: 500
Multiple: 500
Total (€ 0.16 / piece)
€ 80.00
incl. VAT
14-day return policy included
Technical specifications
- Type
PESD15VS2UT,215
- Product type
TVS diode
- Enclosure
SOT 23
- Manufacturer
Nexperia
- Manuf. code
NEX
- Reverse voltage U(R)
15 V
- Breakdown voltage U(BR)
17.6 V
- Terminal voltage U(CL)
40 V
- Peak current I(pp)
5 A
- Power (max) P(TOT)
160 W
- Channels
2
- Polarity
Unidirectional
- Power line protection
No
- Diode capacitance C(D)
32 pF
- Mounting type
Surface-mount
- Operating temperature (max.)
+150 °C
- Operating temperature (min.)
-65 °C
Documents & Downloads
Datasheet
Datasheet 1096223 Nexperia TVS diode PESD15VS2UT,215 SOT 23 17.6 V 160 W
