OLU OMWS35A48MP MPPT für Windgeneratoren und Photovoltaik Anlagen Hybrid controller
EAN:
Part number:
Item no:
Number
Total (€ 82.34 / piece)
€ 82.34
plus VAT.
Highlights & Details
OULU OMWS35A48MP HYBRID CONTROLLER
- With LCD-display
- Var. Control modes
- User defined work modes
Technical specifications
- Rated voltage : 48 V
- Wind rated power 600W
- Solar rated power 300W
- Max charging current 35 A
- No load current (DC) ≤0.03A
- Product type
Hybrid controller
- Dim
(W x H x D) 62 x 145.4 x 167 mm
- Weight
1 kg
- Content
1 pc(s)
- Width
62 mm
- Height
145.4 mm
- Depth
167 mm
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3348511 OLU OMWS35A48MP MPPT für Windgeneratoren und Photovoltaik Anlagen Hybrid controller
Description
Hybrid controller 600 W + 300 W/48 V (controller).
This text is machine translated.
This text is machine translated.
Features
- LCD display: LCD, symbol and text display, clear and intuitive, easy to understand
- Display parameters: Voltage, current, power, load mode, temperature, Power supply, photovoltaics, wind turbine power generation, etc.
- Protection type: Photovoltaics, battery reverse polarity protection, battery interruption protection, overcurrent, overvoltage, overtemperature, overspeed brakie protection, load overcurrent, short-circuit protection, etc.
- Control mode: MPPT boost charging function for wind turbines, PWM discharge function, PWM current and voltage limitation, PWM current and voltage limitation for photovoltaic systems
- User-defined work mode: Normally open mode, light control mode, light control mode and time control mode (user-defined time period + brightness), etc.
Scope of delivery
- 1 x Hybrid controller.
Hints
Spare part for wind generator 3374311
