Name: Omnitronic XDA-2402 PA amplifier RMS power per channel (at 4 Ohm): 1200 W
Brand: Omnitronic
SKU: 1529924
Availability: InStock

1/5

Dispatches on Wed 21 Oct

29 Piece(s)

Sales and shipping:

Number

Piece(s)

Total (€ 559.00 / piece)

€ 559.00

incl. VAT

14-day return policy included

Highlights & Details

Stereo-PA-amplifier with switched-mode power supply 2 x 1200 W

Low weight and height by built-in switched-mode power supply
Loudspeaker input delay and auto-limiter
2 level control
Complete protective circuit package against short-circuit, overheating, DC voltage, switch-on impacts
This text is machine translated.

Power supply: 230 V AC, 50 Hz
Total connection value: 465 W (1/8 Power)
Power (RMS):
Stereo 4 Ohm 2 x 1200 W
Stereo 8 Ohm 2 x 880 W
Frequency range: 30-20,000 Hz
Distortion factor:< 0.02%
Voltage amplification: 36 dB at 8 Ohm
Noise distance:> 100 dB
Input impedance: 20 kOhm (symmetrical), 10 kOhm (asymmetrical)
Input sensitivity: 1.25 V RMS
Connections Input: 2 x XLR
Output: 2 x speaker connections, 2 x loop-through output XLR
Circuit: Class D
Controls: Power switch, volume control per channel, Ground lift switch
LED-display: Protect, Limit, Signal, Power
Protective circuits: short circuit, overheating, DC voltage, switch-on impacts, soft-start
Construction: Steel chassis
TxBxH): 355 x 483 x ground (44 mm (19", 1U)
Weight: 6.4 kg
Shipping weight: 7.75 kg

User & Safety Instructions 1529924 Omnitronic XDA-2402 PA amplifier RMS power per channel (at 4 Ohm): 1200 W

Stereo-PA-amplifier Class-D architecture
Low weight and height by built-in switched-mode power supply
Loudspeaker input delay and auto-limiter
2 level control
LEDs for activated protective circuit (Protect), over-regulation (clip), Signal and Power
Complete protective circuit package against short-circuit, overheating, DC voltage, switch-on impacts
Ground elevator switch against ground loops
Fan cooled
Electronically balanced inputs via XLR panel jack with loop
Loudspeaker outputs via lockable speaker jacks
Rack installation with 1 Height unit

Stereo-PA-amplifier Class-D architecture
Low weight and height by built-in switched-mode power supply
Loudspeaker input delay and auto-limiter
2 level control
LEDs for activated protective circuit (Protect), over-regulation (clip), Signal and Power
Complete protective circuit package against short-circuit, overheating, DC voltage, switch-on impacts
Ground elevator switch against ground loops
Fan cooled
Electronically balanced inputs via XLR panel jack with loop
Loudspeaker outputs via lockable speaker jacks
Rack installation with 1 Height unit
