Oxygen sensor Greisinger GHM GGO370
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Total (€ 275.00 / piece)
€ 275.00
incl. VAT
14-day return policy included
Highlights & Details
Greisinger air oxygen sensor, closed design GGO 370
- Over and under pressure suitable
- Use in gas-tight System
- 36 x 95; (150 mm including kink protection)
- For oxygen measurements in Tauchgas ("Nitrox") optimized sensor
Technical specifications
- Oxygen partial pressure measurement range: 0 ... 11000 hPa O2; Measuring Range Oxygen concentration 0.0... 100.0 % O2; response time: T90
- 25% O2 ± 0.5% O2; working conditions: 0 ... 50°C/0... 95 % r.F. (Non-condensing); ambient pressure 0.5 to 2.0 bar absolute; over/under-pressure: max. 0.25 bar; Storage temperature: -15 to +60 °C; life: at air:> 4 years; sensor element: GOEL 380;device connector: approx. 1.3 m long cable with mini DIN plug housing: with M16 x 1 screw thread
- Product type
Oxygen sensor
- Dim
(L x W) 95 mm x 36 mm
- Width
36 mm
- Length
95 mm
Documents & Downloads
Datasheet
Datasheet 1384587 Oxygen sensor Greisinger GHM GGO370
User & Safety Instructions
User & Safety Instructions 1384587 Oxygen sensor Greisinger GHM GGO370
User & Safety Instructions 1384587 Oxygen sensor Greisinger GHM GGO370
Conformity certificate
Conformity certificate 1384587 Oxygen sensor Greisinger GHM GGO370
Description
Suitable for measurements on the atmosphere, as well as in systems without or with low or low pressure; this type of sensor has a screw thread and can be directly or via hose adapter in almost all systems gas-tight fit
This text is machine translated.
This text is machine translated.
Features
- Designed for oxygen measurements in Tauchgas ("Nitrox") optimized sensor. Also for applications with increased CO2-content.
Scope of delivery
- Sensor
- Hose adaptor
- T-item
Hints
Not suitable for use in "underwater applications" (rebreather, etc.)
System requirements
- GMH 36929.732487 or GMH 3695
