Application
PB Fastener H-1590 Strain relief with strain relief Terminal Ø (max.) 7.4 mm Board thickness (max.) 1.6 mm Polyamide Bla
Product type
Strain relief
Features
with strain relief
Material
Polyamide
Clamp Ø
6.4 mm
Terminal Ø (max.)
7.4 mm
Datasheet (PDF)
EAN:
Part number:
Item no:
Total (€ 0.84 / piece)
€ 0.84
incl. VAT
14-day return policy included
Highlights & Details
PB Fastener H-1590 Strain relief with strain relief Terminal Ø (max.) 7.4 mm Board thickness (max.) 1.6 mm Polyamide Black 1 pc(s)
- For round cable
Our service for you
Technical specifications
- Product type
Strain relief
- Features
with strain relief
- Factory colour
Black
- Material
Polyamide
- Length
50.4 mm
- (Ø)
12.7 mm
- Dim
(Ø x L) 12.7 mm x 50.4 mm
- Clamp Ø
6.4 mm
- Terminal Ø (max.)
7.4 mm
- Board thickness (max.)
1.6 mm
- Max. temperature
+105 °C
- Halogen-free
No
- Content
1 pc(s)
- Manufacturer part #
H-1590
- Type
H-1590
- RoHS-compliant
Yes
- Material (details)
PA 6.6
- Certification marks
UL94V-2 (HE01)
- Temperature range
+105 °C
Documents & Downloads
Datasheet
Datasheet 546598 PB Fastener H-1590 Strain relief with strain relief Terminal Ø (max.) 7.4 mm Board thickness (max.) 1.6 mm Polyamide Bla
User & Safety Instructions
User & Safety Instructions 546598 PB Fastener H-1590 Strain relief with strain relief Terminal Ø (max.) 7.4 mm Board thickness (max.) 1.6 mm Polyamide Bla
Description
Firm, insulated und protected · Quick and easy installation with hand tools · coils helps prevent cable breakage.
(Do not use , if the cable is exposed to extreme vibration)
(Do not use , if the cable is exposed to extreme vibration)
