Name: Phoenix Contact 1501715 Spiral cable 4 x 0.34 mm² 100 m
Brand: Phoenix Contact
SKU: 3452580

A coiled black garden hose, neatly wound with an extended end, on a plain background, suggesting readiness for use.

Product type

Spiral cable

No. of leads

4 x

Cross section (each core)

0.34 mm²

Cable features

PUR coating

Cross section

4 x 0.34 mm²

Datasheet (PDF)

EAN:

Part number:

Item no:

Unavailable

Sales and shipping:

Conrad ElectronicTerms & Conditions

Report legal concerns

Technical specifications

Suitable for laying in the ground: No.
Cable longitudinally watertight: No.
Cable transverse water-proof: No.
Conductor class: Cl. 6 = fine wire
Wire diameter 1.27 mm
Conductor cross-section: 0.34 mm²
Min Permissible bending radius, flexible use/free movement: 50 mm
Min Permitted bending radius, stationary use/fixed installation: 25 mm
Low smoke in accordance with EN IEC 61034-2: No.
Shield over stranding element: Braid
Protection jacket: Without
Specification of wire insulation: Polypropylene (PP)
Ass. Cable outside temperature during assembly/handling: -25-80 °C.
Ass. Cable outside temperature after mounting without vibration: -40-80°C.
Oil resistant according to EN IEC 60811-404: No.

Product type: Spiral cable

No. of leads: 4 x

Cross section (each core): 0.34 mm²

Cross section: 4 x 0.34 mm²

Cable features: PUR coating

Outside Ø: 4.95 mm

Content: 100 m

Bend radius (no. of ODs for fixed installation): 25

Bend radius (no. of ODs for flexible installation): 50

Sold per metre: No

Halogen-free: Yes

Shielded: Yes

Manufacturer part #: 1501715

Insulation material: Polypropylene

Min. temperature range (flexible installation): -25 °C

Max. temperature range (flexible installation): 80 °C

Min. temperature range (fixed installation): -40 °C

Max. temperature range (fixed installation): 80 °C

Max. length sold by the metre: 100 m

Type: SAC-4P-100,0-PUR/SH-0,34

: FALSE

: 0.34 mm²

: Other

: Other

: Other

: Other

: 1.27 mm

: Braiding

: Other

: Class 6 = very flexible

: -25-80 °C

: -40-80 °C

: None

: 4

: FALSE

: FALSE

: 4.95 mm

: FALSE

: Other

: FALSE

: FALSE

: 50 mm

: 25 mm

: Polypropylene (PP)

: Other

Documents & Downloads

Datasheet

Datasheet 3452580 Phoenix Contact 1501715 Spiral cable 4 x 0.34 mm² 100 m

User & Safety Instructions

User & Safety Instructions 3452580 Phoenix Contact 1501715 Spiral cable 4 x 0.34 mm² 100 m

Description

Cable ring, shielded, PUR halogen-free, black gray RAL 7021, 4-wire, Colour: brown, white, blue, black, cable length: 100 m.

This text is machine translated.

Description

Cable ring, shielded, PUR halogen-free, black gray RAL 7021, 4-wire, Colour: brown, white, blue, black, cable length: 100 m.
