Rautronic 35171203 Strand Yellow 915 m
Part number:
Item no:
Product type
Strand
No. of leads
1 x
Outside Ø
0.9 mm
Content
915 m
Insulation material
PVC
Datasheet (PDF)
Number
Total (1 m = € 0.20)
€ 184.87
plus VAT.
Technical specifications
- Product type
Strand
- No. of leads
1 x
- Content
915 m
- Insulation material
PVC
- Cable features
UL-approved
- Outside Ø
0.9 mm
- Nominal voltage
300 V
- AWG max.
28
- AWG (min.)
28
- Halogen-free
No
- Manufacturer part #
35171203
- Factory colour
Yellow
- Core layout
7 x 0.127 mm
- Core layout
7 x 0.127 mm
- Material (details)
Copper tin-plated
- Max. length sold by the metre
915 m
- Sold per metre
Yes
- Test voltage
1.5 kV
- RoHS-compliant
Yes
- Max. temperature range (flexible installation)
105 °C
- Min. temperature range (flexible installation)
-10 °C
- Max. temperature range (fixed installation)
105 °C
- Min. temperature range (fixed installation)
-20 °C
- Type
UL STYLE 1061 AWG 28 GELB
- Standards
Underwriters Laboratories Inc. (UL)
Documents & Downloads
Datasheet
Datasheet 3728584 Rautronic 35171203 Strand Yellow 915 m
User & Safety Instructions
User & Safety Instructions 3728584 Rautronic 35171203 Strand Yellow 915 m
Description
915 meter = 3000 feet, stranded wire, UL STYLE 1061 AWG 28 YELLOW, N.A. UL-approved Shells according to UL AWM Style 1061/10002, inter alia for internal wiring of equipment and control cabinets. Conductor: Copper flex, tinned, conductor structure: 7 x 0.127 mm, insulation: Special PVC, shore hardness (A) 96 ±3, flame resistant according to UL VW-1/CSA FT-1. Conductor resistance: 215 Ω/km at 20° C, electrical strength: Min. 1500 V/50 Hz (1 min.), insulation resistance: Min. 20 MΩ x km, operating voltage: Max. 300 V. Temperature range static/moving: -20 to 105 °C/-10 to 105 °C.
