Buy Renesas ICL7660SCPAZ PMIC - DC/DC voltage regulator Switched-capacitor voltage converter PDIP 8

Two black integrated circuit chips with eight metal pins each on a white background, showing different perspectives of electrical components.

Image similar

Enclosure

PDIP 8

Mounting type

Through-hole

Product type

PMIC - DC/DC voltage regulator

Type

ICL7660SCPAZ

Manufacturer

Renesas

Datasheet (PDF)

Fast track dispatch on Fri, 11 Sep

13 Piece(s)

Sales and shipping:

Conrad Electronic Terms & Conditions

Quantity (Piece(s))

Savings

Package size (plus VAT.)

Volume discounts vary depending on the seller

You save € 0.00

Number

Piece(s)

Total (€ 7.55 / piece)

€ 7.55

plus VAT.

Report legal concerns

Technical specifications

Type: ICL7660SCPAZ

Manufacturer: Renesas

Manuf. code: REN

Enclosure: PDIP 8

Functions: Ratiometric

Output configuration: Positive or negative

Topology: Switched-capacitor voltage converter

Active rectification: No

Channels: 1

Input voltage (min.): 1.5 V

Input voltage (max.): 12 V

Operating temperature (min.): 0 °C

Operating temperature (max.): +70 °C

Output voltages: -1.5 V
+3 V

Voltage output (max.): -12 V
+24 V

Power output: 45 mA

Switching frequency (max.): 35 kHz

Switching frequency (min.): 10 kHz

Mounting type: Through-hole

Content: 1 pc(s)

Output type: Adjustable

Type: E-MOS Voltage converter

Casing: DIL8

Product type: PMIC - DC/DC voltage regulator
