Renkforce RF-3394866 FEH-500 Industrial Ethernet switch
EAN:
Part number:
Item no:
Number
Total (€ 117.64 / piece)
€
Highlights & Details
5-Port Fast Ethernet switch for DIN rail mounting
- DIN rails and wall mounting
- Protection class IP 30
- Wide-range input 12 - 56 V/DC
- LAN Data Transfer Rate: 100 MBit/s
Technical specifications
- Product type
Industrial Ethernet switch
- LAN transfer rate
100 MBit/s
- Working principle
Unmanaged switch
- Ethernet ports
5
- Port type
RJ45
- Weight
315 g
- Width
25 mm
- Height
130 mm
- Depth
98 mm
- Type
FEH-500
IP30
- Operating voltage
12 V DC
- Current consumption
1 A
- Max. ambient temperature
75 °C
- Min. ambient temperature
-40 °C
- Max. operating temperature
75 °C
- Min. operating temperature
-40 °C
- Max. temperature
75 °C
Variants(All information is without VAT, plus shipping costs)
LAN transfer rate
Ethernet ports
Product type
Renkforce RF-3394866 FEH-500 Industrial Ethernet switch
This article
100 MBit/s
5
Industrial Ethernet switch
Minimum order quantity: 1
Multiple: 1
€ 117.64*
Renkforce RF-3336016 GSHS800 Network switch
1000 MBit/s
8
Network switch
Minimum order quantity: 1
Multiple: 1
€ 142.85*
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 1697433 Renkforce RF-3394866 FEH-500 Industrial Ethernet switch
Conformity certificate
Conformity certificate 1697433 Renkforce RF-3394866 FEH-500 Industrial Ethernet switch
Description
This network switch for industrial use optimized. The aluminum housing with protection class IP 30 is suitable for mounting on DIN rail. If required, each of the 5 ports with a link error triggering an alarm. The power supply can also be monitored. The control is via DIP switch
This text is machine translated.
This text is machine translated.
Features
- Max. power consumption: 4 W
- Power input 12 - 56 V/DC terminal strip (2-pin 5 mm)
- Operating temperature: -40 to 75 °C
- LED-display: Link/Act, Speed
- Flow control: IEEE802.3x
- Auto-MDI/MDI-X
- Store and forward
- Full and half duplex
- Protection class IP 30
- Wide-range input 12 - 56 V/DC
- DIN-rail mounting
- Standards: IEEE 802.3 10BaseT, IEEE 802.3u 100 BaseTX, IEEE 802.3x flow control
- Buffer Memory: 448 Kbits
- EMI FCC Class A Part 15, VCCI Class A
- EMS EN61000-4-2 (ESD), EN61000-4-3 (RS), EN61000-4-4 (EFT),
- EN61000-4-5 (Surge), EN61000-4-6 (CS), EN61000-4-8, EN61000-4-11
- Shock IEC 60068-2-27
- Free-fall IEC 60068-2-32
- Vibration IEC 60068-2-6
Scope of delivery
- 5 Port Network Switch
- Quick start guide.
