Rigol DG1062Z Mains-powered 1 µHz - 60 MHz 2-channel Sinus, Rectangle, Triangle, Noise, Arbitrary
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Total (€ 629.41 / piece)
€
Only 5 Piece(s) available
Highlights & Details
Arbitrary function generator DG1062Z
- 60 MHz bandwidth
- 2 channels
- Standard and arbitrary function
- This text is machine translated.
Technical specifications
- Product Dimensions, length: 319 mm
- Offset: ±5V
- Curve Memory: 8 MPts
- Impedance 50 Ω
- Resolution: 14 bit
- Display: Color-TFT
- Signal output type
Sine, square, ramp, pulse, noise, arbitrary
- Frequency range
1 µHz - 60 MHz
- Frequency range (sine)
1 µHz - 60 MHz
- Distortion factor (sine)
<0.075 %
- Frequency range square wave
1 µHz - 25 MHz
- Square wave slew rate
<10 ns
- Frequency range triangle
1 µHz - 1 MHz
- ARB frequency range
1 µHz - 20 MHz
- Wobble function
Lin/log/Step, 1 ms - 500 s
- Internal modulation
AM, FM, PM, ASK, FSK, PSK, PWM
- External modulation
AM, FM, PM, ASK, FSK, PSK, PWM
- Trigger (synchronous)
TTL
- Frequency reading (external)
1 µHz - 200 MHz
- Dim
(W x H) 262 mm x 112 mm
- Weight
3.2 kg
- Height
112 mm
- Width
262 mm
- Max. frequency
60 MHz
Manufacturer's standards (no certificate)
- No. of channels
2-channel
- Display
LCD
- Features
incl. cycle counter
Modulation
- Interfaces
LAN
USB
USB host
- Voltage supply
Mains
- Signal output types
Sinus
Rectangle
Triangle
Noise
Arbitrary
- Type
DG1062Z
- Min. frequency
1 µHz
- Product type
Mains-powered
Variants(All information is without VAT, plus shipping costs)
Calibrated to
Frequency range (sine)
Rigol DG1062Z Mains-powered 1 µHz - 60 MHz 2-channel Sinus, Rectangle, Triangle, Noise, Arbitrary
This article
Manufacturer's standards (no certificate)
1 µHz - 60 MHz
Minimum order quantity: 1
Multiple: 1
€ 629.41*
Rigol DG1022Z Function generator 1 µHz - 25 MHz 2-channel Sinus, Rectangle, Triangle, Noise, Arbitrary
Manufacturer's standards (no certificate)
1 µHz - 25 MHz
Minimum order quantity: 1
Multiple: 1
€ 315.13*
Rigol DG1032Z Mains-powered 1 µHz - 30 MHz 2-channel Sinus, Rectangle, Triangle, Noise, Arbitrary
Manufacturer's standards (no certificate)
1 µHz - 30 MHz
Minimum order quantity: 1
Multiple: 1
€ 368.91*
Rigol DG1032Z Mains-powered Calibrated to (ISO standards) 1 µHz - 30 MHz 2-channel Sinus, Rectangle, Triangle, Noise, Arbitrary
ISO standards
1 µHz - 30 MHz
Minimum order quantity: 1
Multiple: 1
€ 528.57*
Rigol DG1062Z Mains-powered Calibrated to (ISO standards) 1 µHz - 60 MHz 2-channel Sinus, Rectangle, Triangle, Noise, Arbitrary
ISO standards
1 µHz - 60 MHz
Minimum order quantity: 1
Multiple: 1
€ 789.08*
Rigol DG1062Z Mains-powered Calibrated to (DAkkS standards) 1 µHz - 60 MHz 2-channel Sinus, Rectangle, Triangle, Noise, Arbitrary
DAkkS standards
1 µHz - 60 MHz
Minimum order quantity: 1
Multiple: 1
€ 629.41*
Documents & Downloads
Datasheet
Datasheet 806452 Rigol DG1062Z Mains-powered 1 µHz - 60 MHz 2-channel Sinus, Rectangle, Triangle, Noise, Arbitrary
User & Safety Instructions
User & Safety Instructions 806452 Rigol DG1062Z Mains-powered 1 µHz - 60 MHz 2-channel Sinus, Rectangle, Triangle, Noise, Arbitrary
Conformity certificate
Conformity certificate 806452 Rigol DG1062Z Mains-powered 1 µHz - 60 MHz 2-channel Sinus, Rectangle, Triangle, Noise, Arbitrary
Warranty Terms
Warranty Terms 806452 Rigol DG1062Z Mains-powered 1 µHz - 60 MHz 2-channel Sinus, Rectangle, Triangle, Noise, Arbitrary
Description
The modelDG1062Z has 2 full-fledged and independent output channels (with the same specifications) as well as an internal memory of 8 Mpts. In addition to the typical standard functions are over 160 arbitrary signals like ECG, Gauss curves, Lorentzs, Dual Tone, Expotential Rise and fall is integrated. The highest signal quality of 1 ppm, at 14-bit resolution.
Features
- Brush and sweep function
- Cycle Counters
- Harmonic generator up to 8. Order
- Overload-protected outputs
- 8.89 cm large color TFT screen
- 2 independent channels with switchable tracking function.
- This text is machine translated.
Scope of delivery
- BNC cable
- USB cable
- Power cord
- Quick guide.
Hints
The latest software version can be downloaded from the manufacturer.
