Rigol DS1104Z-S Plus Digital 100 MHz 4-channel 1 GS/s 24 MP 8 Bit Digital storage (DSO), Function generator 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Total (€ 651.26 / piece)
€
Only 5 Piece(s) available
Highlights & Details
Rigol DS1104Z-S Plus Digital 100 MHz 4-channel 1 GS/s 24 MP 8 Bit Digital storage (DSO), Function generator 1 pc(s)
- 100 MHz
- No. of analogue inputs 4
Technical specifications
- 100 MHz bandwidth
- 4 Analogue Input Channels
- 8-bit resolution
- 1 mv - 10 V/div
- 24 Mpts memory
- USB memory key
- 2-channel arbitrary generator, 2 MHz
- Displays
Color TFT
- Screen size
17,78 cm
- Time base
5 ns -50 s/DIV
- Vertical deflection
1 mV – 10 V/div
- Input impedance
1 MΩ
- Input coupling
AC, DC, GND
- Input voltage
300 V
- Power supply (details)
115 V/AC; 230 V AC
- Dim
(L x W x H) 122 x 313 x 161 mm
- Weight
3.2 kg
- Height
161 mm
- Length
122 mm
- Width
313 mm
- Display
800 x 480 p
- No. of analogue inputs
4
Manufacturer's standards (no certificate)
- Interfaces
USB
USB host
Ethernet
- Reading category
CAT I
CAT II 300 V
- Oscilloscope features
Digital storage (DSO)
Function generator
- Type
DS1104Z-S Plus
- Bandwidth
100 MHz
- Channel memory depth
24 MP
- Resolution
8 Bit
- Channel sample rate
1 GS/s
- Product type
Digital
Variants(All information is without VAT, plus shipping costs)
Calibrated to
Bandwidth
Rigol DS1104Z-S Plus Digital 100 MHz 4-channel 1 GS/s 24 MP 8 Bit Digital storage (DSO), Function generator 1 pc(s)
This article
Manufacturer's standards (no certificate)
100 MHz
Minimum order quantity: 1
Multiple: 1
€ 651.26*
Rigol DS1074Z-S Plus Digital 70 MHz 4-channel 1 GS/s 24 MP 8 Bit Digital storage (DSO), Function generator 1 pc(s)
Manufacturer's standards (no certificate)
70 MHz
Minimum order quantity: 1
Multiple: 1
€ 609.24*
Rigol DS1074Z-S Plus Digital Calibrated to (ISO standards) 70 MHz 4-channel 1 GS/s 24 MP 8 Bit Digital storage (DSO), Function generator 1 pc(s)
ISO standards
70 MHz
Minimum order quantity: 1
Multiple: 1
Rigol DS1074Z-S Plus Digital Calibrated to (DAkkS standards) 70 MHz 4-channel 1 GS/s 24 MP 8 Bit Digital storage (DSO), Function generator 1 pc(s)
DAkkS standards
70 MHz
Minimum order quantity: 1
Multiple: 1
Rigol DS1104Z-S Plus Digital Calibrated to (ISO standards) 100 MHz 4-channel 1 GS/s 24 MP 8 Bit Digital storage (DSO), Function generator 1 pc(s)
ISO standards
100 MHz
Minimum order quantity: 1
Multiple: 1
Documents & Downloads
Datasheet
Datasheet 1392194 Rigol DS1104Z-S Plus Digital 100 MHz 4-channel 1 GS/s 24 MP 8 Bit Digital storage (DSO), Function generator 1 pc(s)
User & Safety Instructions
User & Safety Instructions 1392194 Rigol DS1104Z-S Plus Digital 100 MHz 4-channel 1 GS/s 24 MP 8 Bit Digital storage (DSO), Function generator 1 pc(s)
User & Safety Instructions 1392194 Rigol DS1104Z-S Plus Digital 100 MHz 4-channel 1 GS/s 24 MP 8 Bit Digital storage (DSO), Function generator 1 pc(s)
Conformity certificate
Conformity certificate 1392194 Rigol DS1104Z-S Plus Digital 100 MHz 4-channel 1 GS/s 24 MP 8 Bit Digital storage (DSO), Function generator 1 pc(s)
Description
The model DS1104Z-S Plus is a 100 MHz 4-channel digital oscilloscope with exceptional properties. LAN and USB control are standard, as well as many mathematical functions. The S-version contains a 2-channel, 25 MHz arbitrary function generator.
The model DS1104Z-S Plus has many functions and special features built-in, without requiring a surcharge to be paid.
Further functions can be activated depending on the requirement optional via Software-Key. Thus remains the oscilloscope even with increased measurement requirements up to date.
The displayed measured curves can be via the front USB Host directly on an optional USB-stick or via the rear USB port on a computer.
The large 17.78 cm TFT color monitor can be reliably all the details.
The sampling rate amounts per channel 500 MSa/s and is in single channel mode bundled, so that a sampling rate of up to 1 GSa/s is achieved.
The ultra-vision technology enables the display of overlapping signal intensity-dependent areas and a memory depth 24 Mpts for a detailed signal display.
These features make the DS1104Z-S Plus to an extraordinary measuring device, which can adapt to your measurement requirements.
This text is machine translated.
The model DS1104Z-S Plus has many functions and special features built-in, without requiring a surcharge to be paid.
Further functions can be activated depending on the requirement optional via Software-Key. Thus remains the oscilloscope even with increased measurement requirements up to date.
The displayed measured curves can be via the front USB Host directly on an optional USB-stick or via the rear USB port on a computer.
The large 17.78 cm TFT color monitor can be reliably all the details.
The sampling rate amounts per channel 500 MSa/s and is in single channel mode bundled, so that a sampling rate of up to 1 GSa/s is achieved.
The ultra-vision technology enables the display of overlapping signal intensity-dependent areas and a memory depth 24 Mpts for a detailed signal display.
These features make the DS1104Z-S Plus to an extraordinary measuring device, which can adapt to your measurement requirements.
This text is machine translated.
Features
- 4 optional special functions such as memory expansion, Serial-Bus-trigger and decoder, Extended Trigger-Kit or real-time recording are now in the free bundle BND MSO/DS1000Z including
- The BND MSO/DS1000Z-bundle contains the options:
- SA-DS1000Z (decoding and trigger tools for the serial buses RS232/UART, I2C and SPI)
- MEM-DS1000Z (memory expansion on 24 Mpts memory depth)
- REC-DS1000Z (recording function for real-time recording and playback of curve shapes)
- AT-DS1000Z (advanced trigger functions for the serial buses RS232/UART, I2C and SPI, Runt, Windows, nth edge, delay, time-out).
- This text is machine translated.
Scope of delivery
- 4x passive probes RP 2200 (200 MHz)
- Power cord
- USB cable
- Manual
- Calibration certificate.
Hints
The latest drivers and software versions can be downloaded free of charge from the manufacturer.
The free Option Bundle BND MSO/DS1000Z than unlock code, or the functions are already in the device.
