Highlights & Details

DSO-2072H DIGITAL OSCILLOSCOPE 3 IN 1

3 in 1 - Oscilloscope, multimeter and waveform generator
8.89 cm LCD color screen (320 x 240 pixels)
USB Type-C interface

Technical specifications

Max. 10,000 wfm/s

Displays: Colour LCD

Screen size: 8.89 cm (3.5")

Time base: 5ns/div - 1000s/div, step by 1- 2-5

Vertical deflection: 10mV/div - 10V/div

Input impedance: 1 MΩ±2%, 16 pF±10 pF

Input coupling: DC, AC, ground

Input voltage: 400 V (DC + AC ,PK - PK)

Power supply (details): 100 - 240 VACRMS, 50/60 Hz, CAT Ⅱ
DC INPUT: 5VDC, 2A

Dim: (L x W x H) 198 x 38 x 96 mm

Weight: 600 g

Height: 96 mm

Length: 198 mm

Width: 38 mm

No. of analogue inputs: 2

: Manufacturer's standards (no certificate)

Interfaces: USB device

Reading category: CAT II 400 V

Oscilloscope features: Handheld
Function generator
Multimeter functions

Type: DSO-2072H

Bandwidth: 70 MHz

Channel memory depth: 8 KP

Resolution: 8 Bit

Channel sample rate: 250 MSa/s

Plastic free packaging: Plastic-free packaging

Product type: Handheld oscilloscope

Documents & Downloads

Datasheet

Datasheet 2380256 VOLTCRAFT DSO-2072H Handheld oscilloscope 70 MHz 2-channel 250 MSa/s 8 KP 8 Bit Handheld, Function generator, Multimeter

User & Safety Instructions

User & Safety Instructions 2380256 VOLTCRAFT DSO-2072H Handheld oscilloscope 70 MHz 2-channel 250 MSa/s 8 KP 8 Bit Handheld, Function generator, Multimeter

Warranty Terms

Warranty Terms 2380256 VOLTCRAFT DSO-2072H Handheld oscilloscope 70 MHz 2-channel 250 MSa/s 8 KP 8 Bit Handheld, Function generator, Multimeter

Download

Download 2380256 VOLTCRAFT DSO-2072H Handheld oscilloscope 70 MHz 2-channel 250 MSa/s 8 KP 8 Bit Handheld, Function generator, Multimeter

Description

Three measuring devices in oneThe digital oscilloscope 3-in-1 from Voltcraft has it in itself in the truest sense of the word.Function 1: Digital oscilloscopeAs an oscilloscope, the DSO-2072H has two channels with a maximum bandwidth of 70 MHz, a maximum sampling rate of 250 MS/s and 8K recording length. The vertical resolution is 8-bit.Function 2: MultimeterThe multimeter can be used in the CATII 1000 V measurement category for voltage, current, resistance, capacitance, continuity and diode function measurements. The auto function simplifies the work processes and TRMS ensures reliable measured values. The display has 20,000 digits.Function 3: Waveform generatorThe waveform generator has a channel with a maximum frequency output of 25MHz and a maximum sampling rate of 125 MS/s.A frequency resolution of 0.1 Hz, 14-bit vertical resolution and a waveform length of 8K allow reliable working.Adequate accessoriesThe DSO-2072H comes with a probe with adjustment tool, a cable from BNC connector to alligator clip, a pair of black and red multimeter leads, a USB cable, a quick start guide and a protective soft case. The enclosed CD contains software and an English operating manual.
