Name: Schneider Electric R9L2C640 R9L2C640 Surge arrester 40 kA Piece 1 pc(s)
Brand: Schneider Electric
SKU: 3342739
Availability: InStock

Schneider Electric R9L2C640 R9L2C640 Surge arrester 40 kA Piece 1 pc(s)-0

Datasheet (PDF)

Dispatches on Tue 20 Oct

23 Piece(s)

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

Piece(s)

Total (€ 87.99 / piece)

€ 87.99

incl. VAT

14-day return policy included

Report legal concerns

Technical specifications

Product type: Surge arrester

Leakage current: 40 kA

Manufacturer part #: R9L2C640

Dim: (W x H x D) 36 x 99 x 70 mm

Width: 36 mm

Height: 99 mm

Depth: 70 mm

Content: 1 pc(s)

Packaging type: Piece

: DIN rail (top hat rail) 35 mm

: TRUE

: 3

: 2 modular spacing

: 1.5 kV

: 275 V

: 20 kA

: 230 V

: TRUE

: 1.5 kV

: Optic

: IP20

: 1.5 kV

: FALSE

: 35 mm²

: 25 mm²

: FALSE

: FALSE

: FALSE

: FALSE

: TRUE

: TRUE

: FALSE

: FALSE

: 40 kA

: 25 kA

: 100 A

: FALSE

: FALSE

UKCA: yes

Documents & Downloads

Datasheet

Datasheet 3342739 Schneider Electric R9L2C640 R9L2C640 Surge arrester 40 kA Piece 1 pc(s)

User & Safety Instructions

User & Safety Instructions 3342739 Schneider Electric R9L2C640 R9L2C640 Surge arrester 40 kA Piece 1 pc(s)

Information

Repairability/durability data sheet 3342739 Schneider Electric R9L2C640 R9L2C640 Surge arrester 40 kA Piece 1 pc(s)

Conformity certificate

Conformity certificate 3342739 Schneider Electric R9L2C640 R9L2C640 Surge arrester 40 kA Piece 1 pc(s)

Description

Acti9 iPRD C40r modular surge suppressor type 2+3 in compact design - only 2TE wide. Max. net current over-current protection 100A gg. Telecommunication contact. Optical function/defect display of arrester (green OK/ red device defective). Suitable for TN-S and TT networks. U0 nominal voltage 230 V AC (50 Hz). UC - highest continuous voltage 255VAC (N-PE) / 275VAC (L-N). In-nominal leakage surge current 20 kA (L-N)/(N-PE). Imax maximum leakage surge current 40 kA (L-N)/(N-PE). Uoc open circuit voltage 6kV (L-N/N-PE). Op. Protection level 1.5 kV (type 2+3) for (L-N/N-PE). Op protection level 1.0 kV (type 3) for (L-N/N-PE). DIN-Rail mount Dimensions (W) 36mm x (H) 99mm x (D) 70mm. Weight 262g. Protection class IP20 integrated. Operating temperature: -40 to +85 oC. COMPLIES WITH IEC 61643-11:2011, EN 61643-11:2012+A11:2018.
