Name: Senseca ECO 210-3-UT Pressure gauge Pressure 200 hPa (max)
Brand: Senseca
SKU: 3046630
Availability: InStock

Handheld manometer device with a digital screen displaying '20'. It features two connectors at the top and buttons for navigation.

Digital manometer with a display showing '20 Pa'. The device has two nozzles at the top, buttons below the screen, and 'senseca' branding.

A portable digital manometer by Senseca, displaying a pressure reading of 20 with '+', '-', and 'OK' buttons beneath the screen.

'Close-up of a blue object with two hexagonal, metallic fixtures resembling screws or connectors on a flat surface.'

A technical setup showing a pressure gauge reading '1104', connected to machinery with wires and tubes, possibly part of an industrial system.

1/5

Datasheet (PDF)

Fast track dispatch on Wed 14 Oct

4 Piece(s)

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

Piece(s)

Total (€ 234.99 / piece)

€ 234.99

incl. VAT

Only 4 Piece(s) available

14-day return policy included

Report legal concerns

Highlights & Details

ECO 210-3 Fine manometer

Technical specifications

Display units Pa, hPa, mbar, PSI, mmHg
Measuring frequency: Slow 2.5 measurements/s; fast 25 measurements/s.
Overload max.: +/- 1700 hPa
Working temperature: -20°C to +50 °C

Power supply (details): 2 x AA battery

Product type: Pressure gauge

Reading range: 200 hPa (max)

Power consumption: 1 mA

Unit of measurement: Pressure

Pneumatic connection: 2 hose connections, changeable through G1/8 universal ports

Reading range: Selectable from -2000..+2000 Pa to -200.0..+200.0 hPa (FINE: -200.0..+200.0 Pa)

: Manufacturer's standards (no certificate)

Display range: Pa, hPa, mbar, PSI, mmHg (Torr)

Print resolution: 0.1 Pa

: IP67

Dim: (L x W x H) 54 x 28 x 108 mm

Weight: 150 g

Accuracy: 0.1 %

Reading range (max.): 200 hPa

Width: 28 mm

Height: 108 mm

Length: 54 mm

Documents & Downloads

Datasheet

Datasheet 3046630 Senseca ECO 210-3-UT Pressure gauge Pressure 200 hPa (max)

User & Safety Instructions

User & Safety Instructions 3046630 Senseca ECO 210-3-UT Pressure gauge Pressure 200 hPa (max)

Description

While developing the new ECO-line the main focus was placed on the essential functions of the measurement technology. The heart of the device - the sensor - is a high-quality component - which is characterized in this device class. The high reliability, speed and precision of the ECO-line versions, packed in a compact and water-protected casing makes the devices an ideal partner for industry and trade, Made in Germany. ECO 210-3 Fine pressure manometer for use in heating, ventilation and air conditioning systems (HVAC). The measurement range up to 200 hPa (mbar) / 20 kPa and the high resolution up to 0.1 Pascal in optimized fine pressure mode cover the main applications for gas pressure 150 hPa (mbar) and burner setting with a single device. The high precision makes it easier, for example, to set compressed air or draft air measurements. The measurement is independent of the orientation of the device - better than with many, also far more expensive, competitors.

Display
3-line segment LCD
Additional symbols
Illuminated (white, light-on time adjustable)
Overhead display at the touch of a button

Standard functions
Min/Max/Hold
Auto power-off function / If activated, the product switches off automatically

Reconciliation
Zero point and slope setting

Housings
Unbreakable ABS casing
Protection type IP67 (pressure connections must be protected against contamination and moisture)
