Shuttle Mini PC workstation DL3000EP Intel® Pentium® N100 3.4 GHz 8 GB RAM 128 GB SSD DL3000EP
Datasheet (PDF)
EAN:
Part number:
Item no:
Highlights & Details
Shuttle DL3000EP Mini PC workstation
- Intel® Pentium® N100 4 core(s) / max. 3.4 GHz
- RAM: 8 GB DDR5 RAM 4800 MHz
- 128 GB SSD
- Windows® 10 IoT Enterprise
Technical specifications
- Processor threads: 4
- Processor boost frequency:3.4 GHz
- Processor cache type: Smart cache
- Storage capacity: 8 GB
- RAM maximum: 16 GB
- Internal memory type DDR5 SDRAM
- Storage layout 1 x 8 GB
- Memory card slots: 1x SO-DIMM
- Storage frequency 4800 MHz
- Memory channels: Single channel
- Total storage capacity 128 GB
- Storage media SSD
- Optical Drive Type: No.
- Number of installed storage drives: 1
- Total SSD capacity 128 GB
- Number of SSDs installed: 1
- SSD storage capacity 128 GB
- SSD form factor M.2
- Built-in graphics adapter: Yes
- Separate video card model: Not available
- Built-in GPU manufacturer Intel
- On-board graphics adapter family: Intel® UHD Graphics
- Built-in graphics card model: Intel® UHD Graphics
- Ethernet/LAN: Yes
- Ethernet LAN data transfer rates of 100,1000,2500 Mbit/s.
- LAN-Controller Intel I226-LM
- USB 3.2 Gen 1 (3.1 Gen 1) Number of C-type connectors: 8
- Number of VGA (D-Sub) Connections: 1
- Number of HDMI connections: 1
- HDMI version: 2.0b
- Number of DisplayPort connections: 1
- DisplayPort version: 1.4a
- Number of Ethernet LAN connections (RJ-45): 2
- Microphone input: Yes
- Headphone outputs: 1
- DC connection (DC): Yes
- Number of serial connections: 2
- Slim PC casing type
- Volume (l) 1.35 l
- Cable lock slot: Yes
- Slot type cable lock Kensington
- Case material: Steel
- Viewing window: No.
- Market Positioning: Business
- Audio chip: Realtek ALC888S
- Password protection: Yes
- BIOS TYPE UEFI AMI
- Trusted Platform Module (TPM): Yes
- Trusted Platform Module (TPM) Version: 2.0
- Product type: Mini PC
- Windows 10 IoT installed
- Operating system architecture: 64-bit
- Drivers included: Yes
- Power supply 65 W
- Power supply - input voltage 100 - 240 V
- Power Supply - Input Frequency 50/60 Hz
- Operating temperature: 0 - 40 °C
- Operating relative humidity: 10 - 90%
- Compliance certificates: BSMI, CE, Federal Communications Commission (FCC), Low Voltage Directive (LVD), RCM, RoHS, UKCA, VCCI
- Sustainability Compliance: Yes
- Sustainability certificates: ENERGY STAR, ERP
- Display included: No.
- Supplied cable: AC
- VESA-bracket included: Yes
- Screws included: Yes
- No fan: Yes
- Product type
Mini PC workstation
- Model
DL3000EP
- CPU series
Intel® Pentium®
- CPU
Intel® Pentium® N100
- Processor/type
N100
- Processor cores (No.)
4 x
- CPU turbo clock speed (max.)
3.4 GHz
- CPU cache
6 MB
8 GB
- RAM type
DDR5 RAM
- Memory clock speed
4800 MHz
- RAM / Max. upgrade
16 GB
- Onboard graphics card
Yes
- SSD size (total)
128 GB
- SSD 1 type
SSD
- SSD
128 GB
- HDD capacity (total)
0 GB
- Hard drive
0 GB
- HDD 1 type
Flash
- Drive
w/o hard drive
- Keyboard layout
Keyboard not included
- No. of DisplayPort
1 x
- No. of Gigabit LANs
2 x
- No. of HDMI ports
1 x
- No. of serial ports
2 x
- No. of USB 3.0 ports
8 x
- No. of VGA ports
1 x
- Interfaces
Headphone input
- Factory colour
Black
- Width
165 mm
- Height
43 mm
- Depth
190 mm
- Weight
800 g
- PSU power
65 W
- Operating system (Version)
Windows® 10 IoT Enterprise
- Graphics card type
Intel UHD Graphics
- Design height
43 mm
- No. of 10 Gb LAN ports
2 x
- Range of uses
Office
- Form factor
M.2 Module
- Power supply (LOV)
mains-powered
- Clock speed
4800 MHz
- No. of HDMI connections
1
- Wi-Fi
No
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 3221550 Shuttle Mini PC workstation DL3000EP Intel® Pentium® N100 3.4 GHz 8 GB RAM 128 GB SSD DL3000EP
User & Safety Instructions
User & Safety Instructions 3221550 Shuttle Mini PC workstation DL3000EP Intel® Pentium® N100 3.4 GHz 8 GB RAM 128 GB SSD DL3000EP
Description
The Shuttle XPC slim barebones of the DL30N series are the successors of the DL20N series. This fanless slim PC barebones with economical Intel "Alder Lake-N" processor of the 12. Generation is suitable both for building especially slim PC-systems with drives and operating system, as well as for purely network-based applications in client/server environments. Two Intel 2.5G network ports provide excellent network connectivity and the optional WWN03 Shuttle accessory allows the installation of an LTE module for mobile Internet access. The integrated graphics are based on Intel's powerful Intel UHD graphics with hardware acceleration for 4K videos. This slim PC works practically silently together with SSD memory.
This text is machine translated.
This text is machine translated.
Features
- Processor family: Intel® N.
- Processor N100
- Storage capacity: 8 GB
- Internal memory type DDR5 SDRAM
- Storage frequency 4800 MHz
- Total storage capacity 128 GB
- Storage media SSD
- Built-in graphics card model: Intel® UHD Graphics
- Windows 10 IoT installed
- Operating system architecture: 64-bit
- Power supply 65 W
- Slim PC casing type
- Product type: Mini PC
- Weight: 800 g
- Product color: Black
Hints
HDMI® is a registered trademark of HDMI Licensing LLC
Image may differ from actual product.
