Name: Siemens 3NJ41413BF01 Switch disconnector fuse Fuse size = 3 630 A 690 V AC, 440 V DC 1 pc(s)
Brand: Siemens
SKU: 2862209

A vertical panel with four black Siemens circuit breakers in a grey enclosure, suitable for industrial electrical installations.

Image similar

Product type

Switch disconnector fuse

Fuse size

Number of pins

Nominal current - rounded value

630 A

Type

In strip design

Datasheet (PDF)

Unavailable

Sales and shipping:

Conrad ElectronicTerms & Conditions

Report legal concerns

Technical specifications

Design of electrical connection / for main circuit: Screw connectionDesign of the device: For 185 mm busbar systemSlim terminal mounting, M 12Suitable for use / switch disconnectors: YesSuitability for use: System protectionMounting type: Permanent installationInbouwpositie loodrechtProtection class IP:IP30Ambient temperature / during operation / minimum: -25 °C.Ambient temperature / during operation / maximum: 55 °C.Power loss/maximum 110 W.Forward current (IC) / at 690 V / maximum permissible: 52 kAInsulation voltage 1000 VRail center distance 185 mm

Type: In strip design

Product type: Switch disconnector fuse

Fuse size: 3

Number of pins: 3

RoHS-compliant: Yes

Dim: (W x H x D) 99.5 x 662 x 195 mm

Content: 1 pc(s)

Nominal current: 630 A

Nominal current - rounded value: 630 A

Nominal voltage: 690 V AC
440 V DC

Width: 99.5 mm

Height: 662 mm

Depth: 195 mm

UKCA: yes

Variants(All information is without VAT, plus shipping costs)

Nominal current - rounded value

Number of pins

Fuse size

Siemens 3NJ41413BF01 Switch disconnector fuse Fuse size = 3 630 A 690 V AC, 440 V DC 1 pc(s)

Item no:2862209

Unavailable

Conrad Electronic

This article

630 A

Piece(s)

Minimum order quantity: 1

Multiple: 1

Siemens 3NC1091 Switch disconnector fuse 32 A 690 V AC, 800 V DC 12 pc(s)

Item no:2262479

Fast track dispatch on Thu 15 Oct

2 Set(s)Conrad Electronic

32 A

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 164.99^*

Siemens 3NJ41013BF01 Switch disconnector fuse Fuse size = 0 160 A 690 V AC, 440 V DC 1 pc(s)

Item no:2862199

Unavailable

Conrad Electronic

160 A

Piece(s)

Minimum order quantity: 1

Multiple: 1

Siemens 3NJ41033CF02 Switch disconnector fuse Fuse size = 00 160 A 690 V AC, 440 V DC 1 pc(s)

Item no:2862200

Unavailable

Conrad Electronic

160 A

Piece(s)

Minimum order quantity: 1

Multiple: 1

Siemens 3NJ41033CF12 Switch disconnector fuse Fuse size = 00 160 A 690 V AC, 440 V DC 1 pc(s)

Item no:2862201

Unavailable

Conrad Electronic

160 A

Piece(s)

Minimum order quantity: 1

Multiple: 1

Siemens 3NJ41213BF01 Switch disconnector fuse Fuse size = 1 250 A 690 V AC, 440 V DC 1 pc(s)

Item no:2862202

Unavailable

Conrad Electronic

250 A

Piece(s)

Minimum order quantity: 1

Multiple: 1

Siemens 3NJ41233BT01 Switch disconnector fuse Fuse size = 1 250 A 690 V AC, 440 V DC 1 pc(s)

Item no:2862203

Unavailable

Conrad Electronic

250 A

Piece(s)

Minimum order quantity: 1

Multiple: 1

Siemens 3NJ41233CF01 Switch disconnector fuse Fuse size = 1 250 A 690 V AC, 440 V DC 1 pc(s)

Item no:2862204

Unavailable

Conrad Electronic

250 A

Piece(s)

Minimum order quantity: 1

Multiple: 1

Siemens 3NJ41233CF11 Switch disconnector fuse Fuse size = 1 250 A 690 V AC, 440 V DC 1 pc(s)

Item no:2862205

Unavailable

Conrad Electronic

250 A

Piece(s)

Minimum order quantity: 1

Multiple: 1

Siemens 3NJ41333BF01 Switch disconnector fuse Fuse size = 2 400 A 690 V AC, 440 V DC 1 pc(s)

Item no:2862206

Unavailable

Conrad Electronic

400 A

Piece(s)

Minimum order quantity: 1

Multiple: 1

Documents & Downloads

Datasheet

Datasheet 2862209 Siemens 3NJ41413BF01 Switch disconnector fuse Fuse size = 3 630 A 690 V AC, 440 V DC 1 pc(s)

User & Safety Instructions

User & Safety Instructions 2862209 Siemens 3NJ41413BF01 Switch disconnector fuse Fuse size = 3 630 A 690 V AC, 440 V DC 1 pc(s)

Description

Fuse disconnect switch term., switchable 1-pin, size 3 I=630A, U=690V Screw connection M12, the 3NJ4 fuse disconnector for low voltage distribution. The 3NJ4 1- or 3-pole switchable fuse switch disconnectors can be used in low-voltage distributors, power and transformer stations and cable distribution cabinets. The Siemens 3NJ4 fuse switch disconnectors are characterized above all by: 1. Complies with IEC/EN 60439-1 and IEC/EN 60947-3. 2. Voltage levels up to AC 690 V. 3. Parking position for maintenance work. 4. Vertical and horizontal installation position. 5. Climatic conditions. 6. Protection class IP30 with closed, IP10 with open grip inserts.
