Siemens 3SE71201BF00 3SE7120-1BF00 Pull cord switch Pull cord latch IP65 1 pc(s)
Datasheet (PDF)
EAN:
Part number:
Item no:
Number
Total (€ 239.99 / piece)
€ 239.99
incl. VAT
14-day return policy included
Technical specifications
- Isolation voltage: 400 V
- Impulse withstand voltage rated value: 6 kV
- Operating current: 6 A
- Packaging type
Piece
- Product type
Pull cord switch
- Connection
Screws
- Operation type
Pull cord
- Contact type
2 breakers
- Contact material
Silver
- Functions
latch
- Weight
400 g
- Factory colour
Black
Grey
- Min. temperature
-25 °C
- Max. temperature
+70 °C
IP65
- Cable length
5 m
- Thread size
M20
- Durability
100000
- Material
Metal
Plastic
- Compatible with (details)
Cable lengths up to 5 m.
- Width
52 mm
- Type
3SE7120-1BF00
- Content
1 pc(s)
- Dim
(W x H x D) 52 x 171 x 54 mm
- RoHS-compliant
Yes
- Height
171 mm
- Depth
54 mm
-25--25 °C
IP65
5 m
2
0
0
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 1739984 Siemens 3SE71201BF00 3SE7120-1BF00 Pull cord switch Pull cord latch IP65 1 pc(s)
User & Safety Instructions
User & Safety Instructions 1739984 Siemens 3SE71201BF00 3SE7120-1BF00 Pull cord switch Pull cord latch IP65 1 pc(s)
Description
Contactor, Size 4, 2-pole, DC-4, Rated operating current 75 A Auxiliary switch 22 (2 NO + 2 NC) DC operation Operating mechanism with varistor 24V DC
