Siemens 3SE71501BD00 3SE7150-1BD00 Pull cord switch Pull cord latch IP65 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Total (€ 201.67 / piece)
€ 201.67
plus VAT.
Technical specifications
- Isolation voltage: 400 V
- Impulse withstand voltage rated value: 6 kV
- Operating current: 6 A
- Packaging type
Piece
- Product type
Pull cord switch
- Connection
Screws
- Operation type
Pull cord
- Contact type
1 breaker
1 maker
- Contact material
Silver
- Functions
latch
- Weight
448 g
- Factory colour
Black
Grey
- Min. temperature
-25 °C
- Max. temperature
+70 °C
IP65
- Cable length
20 m
- Thread size
M20
- Durability
100000
- Material
Metal
Plastic
- Compatible with (details)
Cable lengths up to 25 m.
- Width
52 mm
- Type
3SE7150-1BD00
- Content
1 pc(s)
- Dim
(W x H x D) 52 x 171 x 54 mm
- RoHS-compliant
Yes
- Height
171 mm
- Depth
54 mm
-25--25 °C
IP65
20 m
1
1
0
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 1738890 Siemens 3SE71501BD00 3SE7150-1BD00 Pull cord switch Pull cord latch IP65 1 pc(s)
User & Safety Instructions
User & Safety Instructions 1738890 Siemens 3SE71501BD00 3SE7150-1BD00 Pull cord switch Pull cord latch IP65 1 pc(s)
