Name: Siemens 6GK52080YA005ES6 6GK5208-0YA00-5ES6 Industrial Ethernet switch PoE
Brand: Siemens
SKU: 3403435

Circuit diagram of a Siemens controller, model 6GK5208-0HM00-3ES6. On the left, a listing of multiple ports P1 to P8, on the right indicator LEDs.

Image similar

EAN:

Part number:

Item no:

Unavailable

Sales and shipping:

Conrad ElectronicTerms & Conditions

Report legal concerns

Technical specifications

Product type: Industrial Ethernet switch

LAN transfer rate: 1000 MBit/s

Working principle: Managed switch

Ethernet ports: 8

PoE ports: 8

10/100/1000 Mbps ports: 8 x

Router features: PoE

Type: 6GK5208-0YA00-5ES6

Max. ambient temperature: 70 °C

Min. ambient temperature: -40 °C

: 200

: 200 mm

: 49 mm

: IP65

: 30 W

UKCA: yes

Documents & Downloads

User & Safety Instructions

User & Safety Instructions 3403435 Siemens 6GK52080YA005ES6 6GK5208-0YA00-5ES6 Industrial Ethernet switch PoE

Description

SCALANCE XP208G PoE EEC, IP65, Layer2 IE Switch, 8x 100/1000Mbit/s, M12 ports, 802.3at, 8x30W (max. 240W), LED diagnostics, fault signaling contact, redundant power supply, PROFINET IO Device, network management, can be operated in the redundant ring, dust protection caps, incl. -40°C to +70°C C-PLUG optional. SCALANCE XP208G PoE EEC, IP65, Layer2 IE Switch, 8x 100/1000Mbit/s, M12 ports, 802.3at, 8x30W (max. 240W), LED diagnostics, fault signaling contact, redundant power supply, PROFINET IO Device, network management, can be operated in the redundant ring, dust protection caps, incl. -40°C to +70°C C-PLUG optional.
