Siemens 7LF5300-1 Time synchronizer analogue 230 V AC
Datasheet (PDF)
EAN:
Part number:
Item no:
Number
Total (€ 79.99 / piece)
€ 79.99
incl. VAT
14-day return policy included
Technical specifications
- Number Of Wide division units: 1
- Number of channels: 1
- Switching function type: Normally open contact
- Mounting type: DIN rail
- Operation / off-sync: Yes
- Switching capacity current at 250 V/AC: 16 A.
- Supply voltage frequency max. 50 Hz
- Protection class: IP20
- Minimum switching interval of channel 1: 30 min.
- Product function / direct operation: Yes
- Product function / shift preselection: Yes
- Net weight 83 g
- Product type
Time synchronizer
- Operating voltage
230 V AC
- Channels
1-channel
- Type
analogue
- Type
7LF5300-1
- Manufacturer part #
7LF53001
- Dim
(L x W x H) 64 x 18 x 83 mm
- Width
18 mm
- Height
83 mm
- Length
64 mm
- Switching cycle
24h mode
DIN rail
18
83 mm
64 mm
1
FALSE
FALSE
Normally open contact
1
FALSE
TRUE
TRUE
FALSE
FALSE
TRUE
TRUE
AC
TRUE
0
0
30 min
16 A
15 min
IP20
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 1734665 Siemens 7LF5300-1 Time synchronizer analogue 230 V AC
User & Safety Instructions
User & Safety Instructions 1734665 Siemens 7LF5300-1 Time synchronizer analogue 230 V AC
Description
Synchronous time switch Day 1 NO 230V/50Hz 1 MW
