Buy STANLEY FMHT83550-1 One-handed mounting tool Tradelift Load capacity (max.) 150 kg

A Stanley FatMax one-handed clamp with a silver-black design and yellow accents, suitable for holding or gripping workpieces.

'Stanley FatMax Support Clamp' stands vertically on a base. It has a long rod with a sliding handle for securing workpieces.

A metal clamp with a handle and yellow lever, mounted on a sturdy frame, suitable for workshop or construction work.<br><br>Note: The translation is already in British English and matches the source text's meaning and tone precisely.

A silver and black one-handed G-clamp by Stanley with yellow accents. It is used for securing workpieces.

An adjustable tool holder with a black handle and yellow accent colour, suitable for mounting devices on a vertical rail.

A silver and black hand clamp with yellow accents, marked with 'Stanley Fatmax', stands upright on a white surface.

Metal bench vice with long handle and base, Stanley Fatmax branding on the side.

Construction tool with a yellow handle, long metal shaft, and round base. Tool used for mounting or securing to surfaces.

'Stanley Fatmax TradeLift' tool in packaging. Suitable for lifting and positioning heavy items up to 220 kg. Includes pictures of application examples.

STANLEY FMHT83550-1 One-handed mounting tool Tradelift Load capacity (max.) 150 kg-9

Packaging for a 'Stanley Fatmax TradeLift' Clamp. Shows product illustrations, potential applications and highlights the load-bearing capacity of 120 kg.

'Stanley Fatmax TradeLift' packaging displays a hand clamp with operating lever and 220 kg load capacity. Product design and details highlighted.

Packaging for a Stanley Fatmax ChargeLift with image and text instructions. Demonstrates the tool's functionality and potential applications.

Black and yellow Stanley FatMax measuring tool case with icons and instructions on the side describing functions and operation.

High-angle view of a Stanley Fatmax Box. The box displays safety and usage instructions, along with a yellow and black design.

STANLEY FMHT83550-1 One-handed mounting tool Tradelift Load capacity (max.) 150 kg-15

1/16

Fast track dispatch on Wed, 9 Sep

30 Piece(s)

Sales and shipping:

Conrad Electronic Terms & Conditions

Number

Piece(s)

Total (€ 73.94 / piece)

€ 73.94

plus VAT.

Report legal concerns

Highlights & Details

One-handed mounting tool Tradelift

150 kg lifting capacity
Moulded grip - for comfort and grip
Lever for full release and fine adjustment spatially separated

Technical specifications

Beam length 450 mm
Rod thickness 8 mm
Distance between the centers of the mounting holes: 90, 140 mm

Product type: Door lifter

Max. load capacity: 150 kg

Dim: (L x W x H) 240 x 125 x 450 mm

Weight: 2700 g

Content: 1 pc(s)

Material: Steel

Width: 125 mm

Height: 450 mm

Length: 240 mm

UKCA: yes

Documents & Downloads

User & Safety Instructions

User & Safety Instructions 3132935 STANLEY FMHT83550-1 One-handed mounting tool Tradelift Load capacity (max.) 150 kg

Description

Universal one-handed mounting tool for lifting/lowering, clamping, aligning and holding.
Intuitive operation, step-by-step, easy lifting and dosed lowering without accidental triggering. 8 mm per stroke and possibility of fine adjustment with gradual reduction of the lifting plate by 2.5 mm. Comfortable pump movement from top to bottom - stroke is generated by pressing down the pump lever, possibility for operation also with the foot. Large base plate for additional stability and secure stand, drill holes for additional fixing options.
Angled edge simplifies the sliding of the base under flat objects. Closed metal housing for higher durability and protection of the mechanics from dust and dirt. Safe work, no exposed moving parts, no risk of jamming or injury. Recessed countersink - safety function prevents accidental activation of full release

This text is machine translated.

Scope of delivery

1 Stanley Tradelift™ one-handed mounting tool (single)
