STMicroelectronics L298N PMIC - gate/half-bridge gate drivers Inductive Bipolar Multiwatt 15
Product type
PMIC - gate/half-bridge gate drivers
Enclosure
Multiwatt 15
Interfaces
Logic
Mounting type
Through-hole
Type
L298N
Datasheet (PDF)
EAN:
Part number:
Item no:
Number
Total (€ 6.49 / piece)
€ 6.49
incl. VAT
14-day return policy included
Technical specifications
- Type
L298N
- Product type
PMIC - gate/half-bridge gate drivers
- Enclosure
Multiwatt 15
- Manufacturer
STMicroelectronics
- Manuf. code
STM
- Output configuration
Half-bridge (4)
- Range of uses
DC motors
Relays
Solenoids
Stepper motors
- Interfaces
Logic
- Technology (PMIC)
Bipolar
- Fail safe
Current limiter
Overtemperature
- Input voltage (min.)
4.5 V
- Input voltage (max.)
7 V
- Voltage load (min.)
4.8 V
- Voltage load (max.)
46 V
- Max. output current
2 A
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
+150 °C
- Load type
Inductive
- Mounting type
Through-hole
- Type
Dual Bridge Driver
Documents & Downloads
Datasheet
Datasheet 156128 STMicroelectronics L298N PMIC - gate/half-bridge gate drivers Inductive Bipolar Multiwatt 15
User & Safety Instructions
User & Safety Instructions 156128 STMicroelectronics L298N PMIC - gate/half-bridge gate drivers Inductive Bipolar Multiwatt 15
Description
Integrated circuits from leading manufacturers. Please read our extensive documentation which is free to download.
