Name: TE Connectivity Pin strip (standard) Micro-MaTch Total number of pins 12 Contact spacing: 1.27 mm 8-215464-2 1 pc(s)
Brand: TE Connectivity
SKU: 1005540
Availability: InStock

Red eight-pole slide switch with silver pins, suitable for electronic devices to control electrical circuits.

Product type

Pin strip (standard)

Connector type

Plug, straight

No. of rows

Series

Micro-MaTch

1.27 mm

Datasheet (PDF)

Fast track dispatch on Thu 15 Oct

128 Piece(s) (Only while stocks last)

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

Piece(s)

Total (€ 1.79 / piece)

€ 1.79

incl. VAT

14-day return policy included

Report legal concerns

Highlights & Details

Pin strip

Content: 1 pc(s)
No. of rows: 2
Total number of pins: 12

Our service for you

Technical specifications

Flammability level: UL 94 V-0

Product type: Pin strip (standard)

Connector type: Plug, straight

No. of rows: 2

Connector system: board-to-board

Series: Micro-MaTch

CS: 1.27 mm

Pins per row: 6

Total number of pins: 12

Width: 18.5 mm

Pin shape: Rectangular

Nominal current: 1.50 A

Nominal current - rounded value: 1.5 A

Content: 1 pc(s)

Dim: (L x W x H) 5.2 x 18.5 x 10.0 mm

Connection: Print

Case material: PBT

Manufacturer part #: 8-215464-2

Factory colour: Red

Industrial packaging: No

Insulation material: PBT

Contact material: Copper alloy

Connector contact surface: Nickel plated

Nominal voltage: 230 V AC

Height: 10.0 mm

Length: 5.2 mm

RoHS-compliant: Yes

Connector orientation: Perpendicular (to the PCB)

Max. temperature: +105 °C

Min. temperature: -40 °C

Type: Micro-MaTch

Documents & Downloads

Datasheet

Datasheet 1005540 TE Connectivity Pin strip (standard) Micro-MaTch Total number of pins 12 Contact spacing: 1.27 mm 8-215464-2 1 pc(s)

User & Safety Instructions

User & Safety Instructions 1005540 TE Connectivity Pin strip (standard) Micro-MaTch Total number of pins 12 Contact spacing: 1.27 mm 8-215464-2 1 pc(s)

Information

Information 1005540 TE Connectivity Pin strip (standard) Micro-MaTch Total number of pins 12 Contact spacing: 1.27 mm 8-215464-2 1 pc(s)

Description

Micro Match is a strong series, of spring bar on the circuit board soldered, via pin strips in insulation displacement connection sstechnik, up to the SMD products this series offers a variety of application possibilities.
