Name: Teledyne LeCroy HVD3220 Current probe 1 pc(s)
Brand: Teledyne LeCroy
SKU: 2361661
Availability: BackOrder

Voltage measuring device with probes and cables. Accessories are red and black, suitable for electrical testing and analysis.

EAN:

Part number:

Item no:

Available soon

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

Piece(s)

Total (€ 9,325.00 / piece)

€ 9,325.00

incl. VAT

14-day return policy included

Report legal concerns

Highlights & Details

400 MHz high-voltage differential probe (2 kV)

Up to 0.35% gain accuracy
Models with 2 kV CAT safety rating
Widest differential voltage ranges available
Exceptional common mode suppression ratio (CMRR) over a wide frequency range

Technical specifications

Bandwidth (probe only)
400 MHz
Rise time 10-90%
875 ps
CMRR test limits, 23 C. 80 dB @ DC 60 dB @ 1 MHz
Differential voltage range (500-fold damping): 2000 V (DC + Peak AC) from 35 V / Div to 500 V / Div, up to 1500 V offset
Differential voltage range (250-fold damping): 1000 V (DC + Peak AC) from 14 V / Div to 34.5 V / Div, up to 750 V offset
Differential voltage range (100-fold damping): 400 V (DC + Peak AC) from 7 V / Div to 13.8 V / Div, up to 300 V offset
Differential voltage range (50-fold damping): 200 V (DC + Peak AC) from 500 mV / Div to 6.9 V / Div, up to 150 V offset
Common mode voltage (either input to ground): ± 2000 V (DC + peak AC)
Max. Input voltage to ground (either input to ground): ± 2000 Vpk (nominal, either input to ground)

Product type: Current probe

Compatible with: Teledyne LeCroy

Reading category: CAT III 1000 V
CAT III 1500 V

Compatible with: Teledyne LeCroy HDO4000
Teledyne LeCroy HDO6000

Type: HVD3220

Documents & Downloads

User & Safety Instructions

User & Safety Instructions 2361661 Teledyne LeCroy HVD3220 Current probe 1 pc(s)

Description

Unusual common mode rejection ratio
The CMRR for the probes is exceptional for very high frequencies and significantly improves the measurement capability in noisy hohem environments in power electronics. The high CMRR combined with low probe noise and high offset capability offers superior measurement capabilities compared to other HV differential probes.

High-precision measurements
HVD3220 series probes offer 1% gain accuracy and provide accurate voltage measurements. The Autozero function ensures further measurement accuracy by allowing small offset deviations to be calibrated from the measurement.

Largest application coverage
The HVD3000A series covers the entire range of applications, from 120V/240V switched-mode power supplies to 600V class and 5kV class electrical devices. Each model has the best available gain accuracy, the widest differential and offset voltage range, and a superior CMRR.

1500 VDC CAT III RATING
The HVD3220 supports measurements of solar photovoltaic (PV) with 1500 VDC according to IEC / EN 61010-031: 2015. It has a cat III of 1500 VDC and a cat I of 2000 V (DC + PeakAC).

Complete probe integration
The ProBus interface provides power and communication to the probe, eliminating the need for separate power or batteries. Attenuation is automatically selected based on the setting of the oscilloscope gain range (V / Div).
