TracoPower TBA 1-2413E DC/DC converter (print) 66 mA 1 W No. of outputs: 1 x Content 1 pc(s)
Part number:
Item no:
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
10
-
€ 4.03
30
7% = € 0.27
€ 3.76
50
9% = € 0.37
€ 3.66
Volume discounts vary depending on the seller
You save € 0.00
Number
Minimum order quantity: 10
Total (€ 4.03 / piece)
€
Technical specifications
- Type
TBA 1E
- Min. input voltage
21.6 V DC
- Input voltage (max.)
26.4 V DC
- No. of outputs
1 x
- Max. output current
66 mA
- Output current (max.) - rounded
66 mA
- Efficiency (max.)
82 %
1 W
- Insulation voltage
1500 V DC
- Connection
Solder pins
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
95 °C
- Dim
(L x W x H) 19.50 x 6 x 9.50 mm
- Height
9.50 mm
- Length
19.50 mm
- Width
6 mm
- RoHS-compliant
Yes
- Content
1 pc(s)
- Output voltage (max.)
15.0 V DC
- Output voltage (min.)
15.0 V DC
- Weight
2.30 g
- Product type
DC/DC converter (print)
