TracoPower TEL 8-2415WI DC/DC converter (print) 24 V DC 335 mA 8 W No. of outputs: 1 x Content 1 pc(s)
Datasheet (PDF)
Part number:
Item no:
Number
Minimum order quantity: 10
Total (€ 29.99 / piece)
€ 29.99
incl. VAT
14-day return policy included
Technical specifications
- Product type
DC/DC converter (print)
- Type
TEL 8-2415WI
- Nominal voltage
24 V DC
- Min. input voltage
9 V DC
- Input voltage (max.)
36 V DC
- No. of outputs
1 x
- Max. output current
335 mA
- Output current (max.) - rounded
335 mA
- Efficiency (max.)
86 %
8 W
- Insulation voltage
1500 V DC
- Enclosure
DIL 16
- Connection
Solder pins
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
+80 °C
- Dim
(L x W x H) 24.1 x 14.0 x 12.3 mm
- Height
12.3 mm
- Length
24.1 mm
- Width
14.0 mm
- Output voltage (max.)
24 V DC
- Weight
6.1 g
- Content
1 pc(s)
Compliance & Certifications
Certified by EU Garan
Documents & Downloads
Datasheet
Datasheet 3372976 TracoPower TEL 8-2415WI DC/DC converter (print) 24 V DC 335 mA 8 W No. of outputs: 1 x Content 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3372976 TracoPower TEL 8-2415WI DC/DC converter (print) 24 V DC 335 mA 8 W No. of outputs: 1 x Content 1 pc(s)
Warranty Terms
Warranty Terms 3372976 TracoPower TEL 8-2415WI DC/DC converter (print) 24 V DC 335 mA 8 W No. of outputs: 1 x Content 1 pc(s)
Description
4:1 input range, compact DIL-16 metal housing. Regulated output, E/A-insulation 1500 V/DC. Short-circuit and overload resistance, input filter according to EN 55032, class A.
This text is machine translated.
This text is machine translated.
