TracoPower TEL 8-2422WI DC/DC converter (print) 24 V DC 335 mA 8 W No. of outputs: 2 x Content 1 pc(s)
Part number:
Item no:
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
10
-
€ 26.04
30
4% = € 1.13
€ 24.91
Volume discounts vary depending on the seller
You save € 0.00
Number
Minimum order quantity: 10
Total (€ 26.04 / piece)
€ 260.40
plus VAT.
14-day return policy included
Technical specifications
- Product type
DC/DC converter (print)
- Type
TEL 8-2422WI
- Nominal voltage
24 V DC
- Min. input voltage
9 V DC
- Input voltage (max.)
36 V DC
- No. of outputs
2 x
- Max. output current
335 mA
- Output current (max.) - rounded
335 mA
- Efficiency (max.)
85 %
8 W
- Insulation voltage
1500 V DC
- Enclosure
DIL 16
- Connection
Solder pins
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
+80 °C
- Dim
(L x W x H) 24.1 x 14.0 x 12.3 mm
- Height
12.3 mm
- Length
24.1 mm
- Width
14.0 mm
- Output voltage (max.)
12 V DC
-12 V DC
- Weight
6.1 g
- Content
1 pc(s)
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 3372977 TracoPower TEL 8-2422WI DC/DC converter (print) 24 V DC 335 mA 8 W No. of outputs: 2 x Content 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3372977 TracoPower TEL 8-2422WI DC/DC converter (print) 24 V DC 335 mA 8 W No. of outputs: 2 x Content 1 pc(s)
Warranty Terms
Warranty Terms 3372977 TracoPower TEL 8-2422WI DC/DC converter (print) 24 V DC 335 mA 8 W No. of outputs: 2 x Content 1 pc(s)
Description
4:1 input range, compact DIL-16 metal housing. Regulated output, E/A-insulation 1500 V/DC. Short-circuit and overload resistance, input filter according to EN 55032, class A.
