TracoPower TEL 8-4810WI DC/DC converter (print) 48 V DC 2 A 8 W No. of outputs: 1 x Content 1 pc(s)
Part number:
Item no:
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
10
-
€ 25.20
30
4% = € 1.09
€ 24.11
Volume discounts vary depending on the seller
You save € 0.00
Number
Minimum order quantity: 10
Total (€ 25.20 / piece)
€
Technical specifications
- Type
TEL 8-4810WI
- Nominal voltage
48 V DC
- Min. input voltage
18 V DC
- Input voltage (max.)
75 V DC
- No. of outputs
1 x
- Max. output current
2 A
- Output current (max.) - rounded
2 A
- Efficiency (max.)
78 %
8 W
- Insulation voltage
1500 V DC
- Enclosure
DIL 16
- Connection
Solder pins
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
+80 °C
- Dim
(L x W x H) 24.1 x 14.0 x 12.3 mm
- Height
12.3 mm
- Length
24.1 mm
- Width
14.0 mm
- Content
1 pc(s)
- Output voltage (max.)
3.3 V DC
- Weight
6.1 g
- Product type
DC/DC converter (print)
Documents & Downloads
Datasheet
Datasheet 3371914 TracoPower TEL 8-4810WI DC/DC converter (print) 48 V DC 2 A 8 W No. of outputs: 1 x Content 1 pc(s)
Datasheet 3371914 TracoPower TEL 8-4810WI DC/DC converter (print) 48 V DC 2 A 8 W No. of outputs: 1 x Content 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3371914 TracoPower TEL 8-4810WI DC/DC converter (print) 48 V DC 2 A 8 W No. of outputs: 1 x Content 1 pc(s)
Warranty Terms
Warranty Terms 3371914 TracoPower TEL 8-4810WI DC/DC converter (print) 48 V DC 2 A 8 W No. of outputs: 1 x Content 1 pc(s)
Description
4:1 input range, compact DIL-16 metal housing. Regulated output, E/A-insulation 1500 V/DC. Short-circuit and overload resistance, input filter according to EN 55032, class A.
