TracoPower TEN 20-4811 DC/DC converter (print) 48 V DC 5 V DC 4 A 20 W No. of outputs: 1 x Content 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Minimum order quantity: 10
Total (€ 60.50 / piece)
€ 605.00
plus VAT.
Technical specifications
- Product type
DC/DC converter (print)
- Type
TEN 20-4811
- Nominal voltage
48 V DC
- Min. input voltage
36 V DC
- Input voltage (max.)
75 V DC
- No. of outputs
1 x
- Output voltages
5 V DC
- Max. output current
4 A
- Output current (max.) - rounded
4 A
- Efficiency (max.)
85 %
20 W
- Insulation voltage
1500 V DC
- Connection
Solder pins
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
85 °C
- Dim
(L x W x H) 50.8 x 16.2 x 25.4 mm
- Height
25.4 mm
- Length
50.8 mm
- Width
16.2 mm
- Output voltage (max.)
5 V DC
- Output voltage (min.)
5 V DC
- Weight
30 g
- Content
1 pc(s)
Documents & Downloads
Datasheet
Datasheet 3370364 TracoPower TEN 20-4811 DC/DC converter (print) 48 V DC 5 V DC 4 A 20 W No. of outputs: 1 x Content 1 pc(s)
Datasheet 3370364 TracoPower TEN 20-4811 DC/DC converter (print) 48 V DC 5 V DC 4 A 20 W No. of outputs: 1 x Content 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3370364 TracoPower TEN 20-4811 DC/DC converter (print) 48 V DC 5 V DC 4 A 20 W No. of outputs: 1 x Content 1 pc(s)
Warranty Terms
Warranty Terms 3370364 TracoPower TEN 20-4811 DC/DC converter (print) 48 V DC 5 V DC 4 A 20 W No. of outputs: 1 x Content 1 pc(s)
Description
2:1 input range, short-circuit proof, E/A-insulation 1500 V/DC, input filter according to EN 55022, class A, external on/off.
