TracoPower TEP 150-4815WI DC/DC converter 6.3 A 151.2 W Content 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Total (€ 204.99 / piece)
€ 204.99
incl. VAT
14-day return policy included
Technical specifications
- Input change: ±0.2 %
- Last updated: ±0.4 %
- Setting range output voltage: +20 % (with ext. resistance)
- E/A-insulation: 2250 V/DC
- Operating temperature: -40 to + 75 °C
- Reduction: 2.2 % /K above 50 °C
- Safety/approvals standards: UL 60950-1, IEC/EN 60950-1
- Ripple: -200 mVpk-pk.
- Product type
DC/DC converter
- Type
TEP 150-4815WI
- Min. input voltage
18 V DC
- Input voltage (max.)
75 V DC
- Max. output current
6.3 A
- Output current (max.) - rounded
6.3 A
- Efficiency (max.)
87 %
151.2 W
- Output voltage (max.)
24 V DC
- Content
1 pc(s)
151.2 W
- Output voltage
24 V DC
- Efficiency
87 %
- Input voltage
18 -75 V DC
Compliance & Certifications
Certified by EU Garan
Documents & Downloads
Datasheet
Datasheet 513409 TracoPower TEP 150-4815WI DC/DC converter 6.3 A 151.2 W Content 1 pc(s)
Datasheet 513409 TracoPower TEP 150-4815WI DC/DC converter 6.3 A 151.2 W Content 1 pc(s)
User & Safety Instructions
User & Safety Instructions 513409 TracoPower TEP 150-4815WI DC/DC converter 6.3 A 151.2 W Content 1 pc(s)
Warranty Terms
Warranty Terms 513409 TracoPower TEP 150-4815WI DC/DC converter 6.3 A 151.2 W Content 1 pc(s)
