TracoPower TES 1-1219 DC/DC converter (SMD) 12 V DC 9 V DC 110 mA 1 W No. of outputs: 1 x Content 1 pc(s)
Part number:
Item no:
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
10
-
€ 6.29
30
6% = € 0.38
€ 5.91
Volume discounts vary depending on the seller
You save € 0.00
Number
Minimum order quantity: 10
Total (€ 6.29 / piece)
€ 62.90
plus VAT.
14-day return policy included
Technical specifications
- Product type
DC/DC converter (SMD)
- Type
TES 1-1219
- Nominal voltage
12 V DC
- Min. input voltage
10.8 V DC
- Input voltage (max.)
13.2 V DC
- No. of outputs
1 x
- Output voltages
9 V DC
- Max. output current
110 mA
- Output current (max.) - rounded
110 mA
- Efficiency (max.)
78 %
1 W
- Insulation voltage
1500 V DC
- Enclosure
SMD
- Connection
SMD
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
85 °C
- Dim
(L x W x H) 13.7 x 7 x 8 mm
- Height
8 mm
- Length
13.7 mm
- Width
7 mm
- Output voltage (max.)
9 V DC
- Output voltage (min.)
9 V DC
- Weight
2 g
- Content
1 pc(s)
Documents & Downloads
Datasheet
Datasheet 3370716 TracoPower TES 1-1219 DC/DC converter (SMD) 12 V DC 9 V DC 110 mA 1 W No. of outputs: 1 x Content 1 pc(s)
Datasheet 3370716 TracoPower TES 1-1219 DC/DC converter (SMD) 12 V DC 9 V DC 110 mA 1 W No. of outputs: 1 x Content 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3370716 TracoPower TES 1-1219 DC/DC converter (SMD) 12 V DC 9 V DC 110 mA 1 W No. of outputs: 1 x Content 1 pc(s)
Warranty Terms
Warranty Terms 3370716 TracoPower TES 1-1219 DC/DC converter (SMD) 12 V DC 9 V DC 110 mA 1 W No. of outputs: 1 x Content 1 pc(s)
Description
Compact SMD casing with industry-standard pinning, E/A-insulation 1500 V/DC, high accuracy of Pin-Co-planar intensity. Suitable for lead-free soldering process after IPC/JEDEC J-STD-020C.
