Name: TracoPower THD 12-1211 DC/DC converter (print) 12 V DC 5.1 V DC 2.4 A 12 W No. of outputs: 1 x Content 1 pc(s)
Brand: TracoPower
SKU: 3372881
Availability: BackOrder

An electronic component with the inscription 'TRACO POWER', technical specifications: Input 18-36 VDC, Output 12 VDC/3500 mA, Model THD 12-2410.

Datasheet (PDF)

Available soon

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

Piece(s)

Minimum order quantity: 10

Total (€ 45.99 / piece)

€ 459.90

incl. VAT

14-day return policy included

Report legal concerns

Technical specifications

Product type: DC/DC converter (print)

Type: THD 12-1211

Nominal voltage: 12 V DC

Min. input voltage: 9 V DC

Input voltage (max.): 18 V DC

No. of outputs: 1 x

Output voltages: 5.1 V DC

Max. output current: 2.4 A

Output current (max.) - rounded: 2.4 A

Efficiency (max.): 86 %

: 12 W

Insulation voltage: 1500 V DC

Enclosure: DIL 24

Connection: Solder pins

Operating temperature (min.): -40 °C

Operating temperature (max.): 85 °C

Dim: (L x W x H) 31.8 x 20.3 x 14 mm

Height: 14 mm

Length: 31.8 mm

Width: 20.3 mm

Output voltage (max.): 5.1 V DC

Output voltage (min.): 5.1 V DC

Weight: 18 g

Content: 1 pc(s)

Compliance & Certifications

Certified by EU Garan

Variants(All information include VAT, plus shipping costs)

Output voltages

Input voltage (max.)

Output current (max.) - rounded

Output voltage (max.)

Nominal voltage

Min. input voltage

TracoPower THD 12-1211 DC/DC converter (print) 12 V DC 5.1 V DC 2.4 A 12 W No. of outputs: 1 x Content 1 pc(s)

Item no:3372881

Available soon

Conrad Electronic

This article

5.1 V DC

18 V DC

2.4 A

5.1 V DC

12 V DC

9 V DC

Piece(s)

Minimum order quantity: 10

Multiple: 1

€ 45.99^*

TracoPower THD 12-1209 DC/DC converter (print) 12 V DC 2.5 V DC 3.5 A 12 W No. of outputs: 1 x Content 1 pc(s)

Item no:3370788

Available soon

Conrad Electronic

2.5 V DC

18 V DC

3.5 A

2.5 V DC

12 V DC

9 V DC

Piece(s)

Minimum order quantity: 10

Multiple: 1

€ 47.99^*

TracoPower THD 12-1210 DC/DC converter (print) 12 V DC 3.3 V DC 3.5 A 12 W No. of outputs: 1 x Content 1 pc(s)

Item no:3370789

Available soon

Conrad Electronic

3.3 V DC

18 V DC

3.5 A

3.3 V DC

12 V DC

9 V DC

Piece(s)

Minimum order quantity: 10

Multiple: 1

€ 47.99^*

TracoPower THD 12-1212 DC/DC converter (print) 12 V DC 12 V DC 1 A 12 W No. of outputs: 1 x Content 1 pc(s)

Item no:3370790

Available soon

Conrad Electronic

12 V DC

18 V DC

1 A

12 V DC

9 V DC

Piece(s)

Minimum order quantity: 10

Multiple: 1

€ 45.99^*

TracoPower THD 12-1222 DC/DC converter (print) 12 V DC 12 V DC, -12 V DC 500 mA 12 W No. of outputs: 2 x Content 1 pc(s)

Item no:3372882

Available soon

Conrad Electronic

12 V DC

18 V DC

500 mA

12 V DC

9 V DC

Piece(s)

Minimum order quantity: 10

Multiple: 1

€ 48.99^*

TracoPower THD 12-1223 DC/DC converter (print) 12 V DC 15 V DC, -15 V DC 400 mA 12 W No. of outputs: 2 x Content 1 pc(s)

Item no:3372883

Available soon

Conrad Electronic

15 V DC

18 V DC

400 mA

15 V DC

12 V DC

9 V DC

Piece(s)

Minimum order quantity: 10

Multiple: 1

€ 42.99^*

TracoPower DC/DC converter (print) 12 V DC 12 V DC 1 A 12 W No. of outputs: 1 x Content 10 pc(s)

Item no:2791599

Unavailable

Conrad Electronic

12 V DC

18 V DC

1 A

12 V DC

9 V DC

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 415.00^*

TracoPower DC/DC converter (print) 12 V DC 12 V DC, -12 V DC 500 mA 12 W No. of outputs: 2 x Content 10 pc(s)

Item no:2794108

Unavailable

Conrad Electronic

12 V DC

18 V DC

500 mA

12 V DC

9 V DC

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 435.00^*

TracoPower DC/DC converter (print) 12 V DC 15 V DC, -15 V DC 400 mA 12 W No. of outputs: 2 x Content 10 pc(s)

Item no:2794109

Unavailable

Conrad Electronic

15 V DC

18 V DC

400 mA

15 V DC

12 V DC

9 V DC

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 435.00^*

TracoPower DC/DC converter (print) 12 V DC 2.5 V DC 3.5 A 12 W No. of outputs: 1 x Content 10 pc(s)

Item no:2791600

Unavailable

Conrad Electronic

2.5 V DC

36 V DC

3.5 A

2.5 V DC

12 V DC

18 V DC

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 419.00^*

Documents & Downloads

Datasheet

Datasheet 3372881 TracoPower THD 12-1211 DC/DC converter (print) 12 V DC 5.1 V DC 2.4 A 12 W No. of outputs: 1 x Content 1 pc(s)

User & Safety Instructions

User & Safety Instructions 3372881 TracoPower THD 12-1211 DC/DC converter (print) 12 V DC 5.1 V DC 2.4 A 12 W No. of outputs: 1 x Content 1 pc(s)

Warranty Terms

Warranty Terms 3372881 TracoPower THD 12-1211 DC/DC converter (print) 12 V DC 5.1 V DC 2.4 A 12 W No. of outputs: 1 x Content 1 pc(s)

Description

High power density in the DIL-24 metal housing, 2:1 input range, input/output insulation 1500 V/DC, short-circuit proof, external on/off, input filter according to EN 55022, class A.

This text is machine translated.
