TracoPower THM 20-4822 DC/DC converter (print) 833 mA 20 W No. of outputs: 2 x Content 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Sales and shipping:
Number
Minimum order quantity: 10
Total (€ 72.26 / piece)
€
Technical specifications
- Product type
DC/DC converter (print)
- Type
THM 20-4822
- Min. input voltage
36 V DC
- Input voltage (max.)
75 V DC
- No. of outputs
2 x
- Max. output current
833 mA
- Output current (max.) - rounded
833 mA
- Efficiency (max.)
89 %
20 W
- Insulation voltage
5000 V AC
- Connection
Solder pins
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
80 °C
- Dim
(L x W x H) 40.60 x 25.40 x 10.20 mm
- Height
10.20 mm
- Length
40.60 mm
- Width
25.40 mm
- RoHS-compliant
Yes
- Output voltage (max.)
12 V DC
-12 V DC
- Output voltage (min.)
12 V DC
-12 V DC
- Weight
24 g
- Content
1 pc(s)
