TracoPower THN 15-2421N DC/DC converter (print) 1.5 A 15 W No. of outputs: 2 x Content 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Minimum order quantity: 10
Total (€ 38.65 / piece)
€ 386.50
plus VAT.
Technical specifications
- Product type
DC/DC converter (print)
- Type
THN 15-2421N
- Min. input voltage
18 V DC
- Input voltage (max.)
36 V DC
- No. of outputs
2 x
- Max. output current
1.5 A
- Output current (max.) - rounded
1.5 A
- Efficiency (max.)
86 %
15 W
- Insulation voltage
1600 V DC
- Connection
Solder pins
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
70 °C
- Dim
(L x W x H) 25.40 x 25.40 x 9.90 mm
- Height
9.90 mm
- Length
25.40 mm
- Width
25.40 mm
- RoHS-compliant
Yes
- Output voltage (max.)
5.0 V DC
-5.0 V DC
- Output voltage (min.)
5.0 V DC
-5.0 V DC
- Weight
16.50 g
- Content
1 pc(s)
- UKCA
yes
