TracoPower TMV 2-1205SHI DC/DC converter (print) 12 V DC 5 V DC 400 mA 1 W No. of outputs: 1 x Content 1 pc(s)
Datasheet (PDF)
Part number:
Item no:
Number
Minimum order quantity: 10
Total (€ 13.99 / piece)
€ 13.99
incl. VAT
14-day return policy included
Technical specifications
- Product type
DC/DC converter (print)
- Type
TMV 2-1205SHI
- Nominal voltage
12 V DC
- Min. input voltage
11.8 V DC
- Input voltage (max.)
13.2 V DC
- No. of outputs
1 x
- Output voltages
5 V DC
- Max. output current
400 mA
- Output current (max.) - rounded
400 mA
- Efficiency (max.)
81 %
1 W
- Insulation voltage
3000 V DC
- Enclosure
SIL 7
- Connection
Solder pins
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
80 °C
- Dim
(L x W x H) 19.5 x 13.4 x 7.1 mm
- Height
7.1 mm
- Length
19.5 mm
- Width
13.4 mm
- Output voltage (max.)
5 V DC
- Output voltage (min.)
5 V DC
- Weight
2.4 g
- Content
1 pc(s)
Compliance & Certifications
Certified by EU Garan
Documents & Downloads
Datasheet
Datasheet 3371390 TracoPower TMV 2-1205SHI DC/DC converter (print) 12 V DC 5 V DC 400 mA 1 W No. of outputs: 1 x Content 1 pc(s)
Datasheet 3371390 TracoPower TMV 2-1205SHI DC/DC converter (print) 12 V DC 5 V DC 400 mA 1 W No. of outputs: 1 x Content 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3371390 TracoPower TMV 2-1205SHI DC/DC converter (print) 12 V DC 5 V DC 400 mA 1 W No. of outputs: 1 x Content 1 pc(s)
Warranty Terms
Warranty Terms 3371390 TracoPower TMV 2-1205SHI DC/DC converter (print) 12 V DC 5 V DC 400 mA 1 W No. of outputs: 1 x Content 1 pc(s)
Description
Compact SIL7-casing, E/A-insulation 5200 V/DC, suitable for IGBT applications, unregulated output.
This text is machine translated.
This text is machine translated.
