TracoPower TRI 20-4813 DC/DC converter (print) 1.333 A 20 W No. of outputs: 1 x Content 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Minimum order quantity: 10
Total (€ 77.30 / piece)
€
Technical specifications
- Type
TRI 20-4813
- Min. input voltage
36 V DC
- Input voltage (max.)
75 V DC
- No. of outputs
1 x
- Max. output current
1.333 A
- Output current (max.) - rounded
1.33 A
- Efficiency (max.)
90 %
20 W
- Insulation voltage
4200 V AC
- Connection
Solder pins
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
76 °C
- Dim
(L x W x H) 50.80 x 25.40 x 12 mm
- Height
12 mm
- Length
50.80 mm
- Width
25.40 mm
- RoHS-compliant
Yes
- Content
1 pc(s)
- Output voltage (max.)
15.0 V DC
- Output voltage (min.)
15.0 V DC
- Weight
30 g
- Product type
DC/DC converter (print)
