TracoPower TRV 1-1513M DC/DC converter (print) 67 mA 1 W No. of outputs: 1 x Content 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Minimum order quantity: 10
Total (€ 17.99 / piece)
€ 179.90
incl. VAT
14-day return policy included
Technical specifications
- Product type
DC/DC converter (print)
- Type
TRV 1-1513M
- Min. input voltage
12 V DC
- Input voltage (max.)
18 V DC
- No. of outputs
1 x
- Max. output current
67 mA
- Output current (max.) - rounded
67 mA
- Efficiency (max.)
84 %
1 W
- Insulation voltage
5000 V DC
- Connection
Solder pins
- PSU features
DC-to-DC converter
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
85 °C
- Dim
(L x W x H) 19.6 x 9.9 x 12.5 mm
- Height
12.5 mm
- Length
19.6 mm
- Width
9.9 mm
- RoHS-compliant
Yes
- Output voltage (max.)
15.0 V DC
- Output voltage (min.)
15.0 V DC
- Weight
4.8 g
- Content
1 pc(s)
Compliance & Certifications
Certified by EU Garan
Documents & Downloads
Datasheet
Datasheet 3372523 TracoPower TRV 1-1513M DC/DC converter (print) 67 mA 1 W No. of outputs: 1 x Content 1 pc(s)
Datasheet 3372523 TracoPower TRV 1-1513M DC/DC converter (print) 67 mA 1 W No. of outputs: 1 x Content 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3372523 TracoPower TRV 1-1513M DC/DC converter (print) 67 mA 1 W No. of outputs: 1 x Content 1 pc(s)
Warranty Terms
Warranty Terms 3372523 TracoPower TRV 1-1513M DC/DC converter (print) 67 mA 1 W No. of outputs: 1 x Content 1 pc(s)
