TracoPower TSR 0.5-2490SM DC/DC converter (SMD) 24 V DC 12 V DC 500 mA No. of outputs: 1 x Content 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 9.24
3
6% = € 0.53
€ 8.71
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 9.24 / piece)
€ 9.24
plus VAT.
Only 6 Piece(s) available
Technical specifications
- Product type
DC/DC converter (SMD)
- Type
TSR 0.5-2490SM
- Nominal voltage
24 V DC
- Min. input voltage
9 V DC
- Input voltage (max.)
18 V DC
- No. of outputs
1 x
- Output voltages
12 V DC
- Max. output current
500 mA
- Output current (max.) - rounded
500 mA
- Efficiency (max.)
96 %
- Enclosure
SMD
- Connection
SMD
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
85 °C
- Dim
(L x W x H) 15.3 x 13 x 9.24 mm
- Height
9.24 mm
- Length
15.3 mm
- Width
13 mm
- Output voltage (max.)
9 V DC
- Output voltage (min.)
9 V DC
- Weight
1.7 g
- Content
1 pc(s)
- Type
TSR 0.5-2490 SM
Documents & Downloads
Datasheet
Datasheet 1511311 TracoPower TSR 0.5-2490SM DC/DC converter (SMD) 24 V DC 12 V DC 500 mA No. of outputs: 1 x Content 1 pc(s)
Datasheet 1511311 TracoPower TSR 0.5-2490SM DC/DC converter (SMD) 24 V DC 12 V DC 500 mA No. of outputs: 1 x Content 1 pc(s)
Warranty Terms
Warranty Terms 1511311 TracoPower TSR 0.5-2490SM DC/DC converter (SMD) 24 V DC 12 V DC 500 mA No. of outputs: 1 x Content 1 pc(s)
Description
Not insulated converters in the compact SMD housing. Short-circuit proof, adjustable output voltage, excellent behavior in the case of input and load change, low standby current.
