TracoPower TVN 3-0923 DC/DC converter (print) 9 V DC 100 mA 3 W No. of outputs: 2 x Content 1 pc(s)
Part number:
Item no:
Datasheet (PDF)
Number
Minimum order quantity: 10
Total (€ 41.17 / piece)
€ 411.70
plus VAT.
14-day return policy included
Technical specifications
- Product type
DC/DC converter (print)
- Type
TVN 3-0923
- Nominal voltage
9 V DC
- Min. input voltage
4.5 V DC
- Input voltage (max.)
13.2 V DC
- No. of outputs
2 x
- Max. output current
100 mA
- Output current (max.) - rounded
100 mA
- Efficiency (max.)
81 %
3 W
- Insulation voltage
1600 V DC
- Enclosure
SIL 8
- Connection
Solder pins
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
+90 °C
- Dim
(L x W x H) 9.6 x 21.8 x 15.3 mm
- Height
15.3 mm
- Length
9.6 mm
- Width
21.8 mm
- Output voltage (max.)
15 V DC
-15 V DC
- Weight
5.9 g
- Content
1 pc(s)
Documents & Downloads
Datasheet
Datasheet 3371886 TracoPower TVN 3-0923 DC/DC converter (print) 9 V DC 100 mA 3 W No. of outputs: 2 x Content 1 pc(s)
Datasheet 3371886 TracoPower TVN 3-0923 DC/DC converter (print) 9 V DC 100 mA 3 W No. of outputs: 2 x Content 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3371886 TracoPower TVN 3-0923 DC/DC converter (print) 9 V DC 100 mA 3 W No. of outputs: 2 x Content 1 pc(s)
Warranty Terms
Warranty Terms 3371886 TracoPower TVN 3-0923 DC/DC converter (print) 9 V DC 100 mA 3 W No. of outputs: 2 x Content 1 pc(s)
Description
2:1 input range, compact SIL-8 metal housing. Low ripple of 10 mVpp type. Regulated output, input/output insulation 1600 V/DC. Short-circuit protection, input filter according to EN 55032, class B with ext. Components.
