TrendNet TV-IP345PI LAN IP CCTV camera 2688 x 1520 p
Datasheet (PDF)
EAN:
Part number:
Item no:
Highlights & Details
LAN IP-Dome camera;2688 x 1520 p;TrendNet;TV-IP345PIOutdoors
- 4 MP HD Video with 30fps in H.264 compression format
- Night vision for highly detailed 24-hour monitoring
- Motor zoom lens
Technical specifications
- Supported Video Formats: 3GPP, H.264, M-JPEG
- Product type
CCTV camera
- CCTV features
IR LEDs
- Camera type
Dome camera
- Power supply
PoE (Power over Ethernet)
- Resolution (max.)
2688 x 1520 p
- Sensor size
8.5 mm (1/3")
- Sensor type
CMOS
- Focal length
2,8 - 12 mm
- Max. viewing angle hor.
103°
- Vertical viewing angle
56°
- App compatibility
Yes
- Transfer type
LAN
- Light sensitivity (+ IR)
0.08 lx
- Light sensitivity (- IR)
0.031 lx
- IR range (max.)
20 m
- Used at
Outdoors
- Type
microSD card (up to 64 GB)
- Width
137 mm
- Height
102 mm
- Depth
137 mm
- Dim
(W x H x D) 137 x 102 x 137 mm
- Weight
962 g
- F-numbers
F1.4
- Factory colour
Grey
IP66
- Signal standard
IP
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 1842649 TrendNet TV-IP345PI LAN IP CCTV camera 2688 x 1520 p
User & Safety Instructions
User & Safety Instructions 1842649 TrendNet TV-IP345PI LAN IP CCTV camera 2688 x 1520 p
Description
The Indoor/Outdoor 4 MP Full-HD PoE dome network camera with motorized IR Varifokal offers powerful 4 MP Full-HD night vision with 30 fps in complete darkness to up to 20 m. This camera with weather protection class IP66 allows manual pan/tilt and has auto-focus/optical zoom (4.2-fold), which flexibility and time savings during installation. GPIO ports and 2-way audio connections for the demanding environment. 120 db WDR, H.264+ compression and much more complete the picture.
This text is machine translated.
This text is machine translated.
Features
- Better image quality, via manual pan/tilt, users can capture the exact field of vision, and the 4.2-times optical zoom with Auto focus improves the image quality and offers more details and focus
- Suitable for outdoor use, developed for extreme conditions with weather protection class IP66 and operating temperature range of -20 to 60 °C
- Power over Ethernet (PoE)
Scope of delivery
- TV-IP 345 PI camera
- User manual for quick installation
- CD-ROM (auxiliary program, software and user manual)
- Mounting material.
