Technical specifications
- Conductor class: Normal flexibility
- With ground wire: No.
- Jacket material: Rubber
- Min Permitted bending radius, stationary use/fixed installation: 156 mm
- Product type
Power feed
- Cable type
H01N2-D
- No. of leads
1 x
- Cross section (each core)
35 mm²
- No. of leads (part 2)
1 x
- Cross section (each core) (part 2)
35 mm²
- Cross section
1 x 35 mm² + 1 x 35 mm²
- Cable features
Flat
Flexible
- Outside Ø
13.00 mm
- Factory colour
Black
- Content
50 m
- Nominal voltage
100 V
- Nominal voltage U0
100 V
- Packaged
Yes
- Sold per metre
Yes
- Manufacturer part #
VER H01N2-D 35 Ri. 50
- Insulation material
Rubber
- Min. temperature range (flexible installation)
-25 °C
- Max. temperature range (flexible installation)
80 °C
- Min. temperature range (fixed installation)
-40 °C
- Max. temperature range (fixed installation)
80 °C
- Max. length sold by the metre
50 m
- Type
VER H01N2-D 35 Ri. 50
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3336923 VER H01N2-D 35 Ri. 50 Power feed H01N2-D 1 x 35 mm² Black 50 m
Description
Complies with VDE 0282. Special cable for transmitting high currents from electric welder to the welding tool. Suitable for flexible use under harsh conditions in dry and damp rooms as well as in the open. The cable retains its high flexibility even under the influence of light, ozone, oxygen, protected gas or oil and is also resistant to cold, heat and fire. Max. operating temperature: 80 °C
This text is machine translated.
This text is machine translated.
Hints
Made in Europe
