Technical specifications
- Conductor material: Copper
- Conductor class: Single-wire
- Fire classification to EN 13501-6: ECA
- Wire color: Red
- Working temperature 5 - 70 °C
- Oil resistant according to EN 60811-404: No.
- Cold resistant according to EN 60811-504+505+506: No.
- Smoke arm according to IEC 61034-2: No.
- Product type
Wire core
- Cable type
H05V-U
- No. of leads
1 x
- Cross section (each core)
0.50 mm²
- No. of leads (part 2)
1 x
- Cross section (each core) (part 2)
0.50 mm²
- Cross section
1 x 0.50 mm² + 1 x 0.50 mm²
- Cable features
Flat
Flexible
- Outside Ø
2.02 mm
- Factory colour
Red
- Content
100 m
- Nominal voltage
500 V
- Nominal voltage U0
300 V
- Packaged
Yes
- Sold per metre
No
- Manufacturer part #
VER H05V-U 0,5 rt Eca Ri100
- Insulation material
Polyvinyl chloride
- Max. temperature range (fixed installation)
70 °C
- Max. length sold by the metre
100 m
- Type
VER H05V-U 0,5 rt Eca Ri100
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3337535 VER H05V-U 0,5 rt Eca Ri100 Wire core H05V-U 1 x 0.50 mm² Red 100 m
Description
Complies with VDE 0281. In dry rooms, in devices, switchgear and distributors, in pipes on and under plaster as well as in closed installation channels. In protected laying in and at lights. In and on electronic equipment in power plants for the purpose of measuring, controlling and regulating. Not permitted for direct installation in walls. Max. operating temperature: 70 °C
This text is machine translated.
This text is machine translated.
Hints
Made in Europe
