Technical specifications
- Conductor class: Fine strands
- Specification Wire insulation: Rubber - ethylene propylene rubber (EPR)
- With ground wire: Yes
- Jacket material: Polyurethane (PUR)
- Min Permitted bending radius, stationary use/fixed installation: 36 mm
- Cable geometry: Round
- Smoke arm according to IEC 61034-2: No.
- Min Permissible bending radius, flexible use/free movement: 54 mm
- Product type
Power feed
- Cable type
H07BQ-F
- No. of leads
3 G
- Cross section (each core)
1.50 mm²
- No. of leads (part 2)
3 G
- Cross section (each core) (part 2)
1.50 mm²
- Cross section
3 G 1.50 mm² + 3 G 1.50 mm²
- Cable features
Flat
Flexible
- Outside Ø
8.90 mm
- Factory colour
Orange
- Content
50 m
- Nominal voltage
750 V
- Nominal voltage U0
450 V
- Packaged
Yes
- Sold per metre
No
- Manufacturer part #
VER H07BQ-F 3G 1,5 Ri. 50
- Insulation material
Gum elastic
- Min. temperature range (flexible installation)
-40 °C
- Max. temperature range (flexible installation)
80 °C
- Min. temperature range (fixed installation)
-40 °C
- Max. temperature range (fixed installation)
80 °C
- Max. length sold by the metre
50 m
- Type
VER H07BQ-F 3G 1,5 Ri. 50
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3336093 VER H07BQ-F 3G 1,5 Ri. 50 Power feed H07BQ-F 3 G 1.50 mm² Orange 50 m
Description
Complies with VDE 0282. Device connecting cable for use in dry, damp or wet environments with an average mechanical load, e.g. for connecting agricultural or commercial equipment, heaters, provided there is no risk of contact with hot parts or heat radiation. Resistant to oil, grease, petrol, water and weather influences, ozone and oxygen, UV rays, hydrolysis and microbes. Max. Operating temperature (fixed installation) 90 °C.
This text is machine translated.
This text is machine translated.
Hints
Made in Europe
