Technical specifications
- Conductor material: Copper
- Conductor class: Fine strands
- Working temperature 5 - 70 °C
- Oil resistant according to EN 60811-404: No.
- Cold resistant according to EN 60811-504+505+506: No.
- Smoke arm according to IEC 61034-2: No.
- Product type
Wire core
- Cable type
(H)07V-K
- No. of leads
1 x
- Cross section (each core)
2.50 mm²
- No. of leads (part 2)
1 x
- Cross section (each core) (part 2)
2.50 mm²
- Cross section
1 x 2.50 mm² + 1 x 2.50 mm²
- Cable features
Flat
Flexible
- Outside Ø
3.60 mm
- Factory colour
Red white
- Content
100 m
- Nominal voltage
750 V
- Nominal voltage U0
450 V
- Packaged
Yes
- Sold per metre
No
- Manufacturer part #
VER H07V-K 2,5 rt/ws Ri.100
- Insulation material
Polyvinyl chloride
- Min. temperature range (fixed installation)
5 °C
- Max. temperature range (fixed installation)
70 °C
- Max. length sold by the metre
100 m
- Type
VER H07V-K 2,5 rt/ws Ri.100
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3335794 VER H07V-K 2,5 rt/ws Ri.100 Wire core (H)07V-K 1 x 2.50 mm² Red white 100 m
Description
Complies with VDE 0281. For laying in dry rooms, in devices, switchgear and distributors, in pipes on or under plaster as well as in closed installation channels. In protected laying in and at lights. Max. operating temperature: 70 °C
This text is machine translated.
This text is machine translated.
Hints
Made in Europe
