Image similar
Technical specifications
- Conductor class: Single-wire
- Wire identification color + rings
- Jacket material: Polyvinyl chloride (PVC)
- Fire classification to EN 13501-6: ECA
- Wire diameter 0.6 mm
- Number of rope elements: 2
- Wire rope element: Four-fold
- Shield over wire element: Without
- Wiring: Bundle
- Shield over stranding: Without
- Cable longitudinally watertight: No.
- Cable transverse water-proof: No.
- Protection jacket: Without
- Min Permitted bending radius, stationary use/fixed installation: 65 mm
- Product type
Data cable
- Cable type
J-YY
- No. of leads
8 x
- Cross section (each core)
0.6 mm²
- Twisted pair cabling (part 1)
Yes (1)
- Cross section
4 x 2 x 0.6 mm²
- Outside Ø
6.50 mm
- Factory colour
Grey
- Content
100 m
- Packaged
Yes
- Manufacturer part #
VER J-YY 4x2x0,6 Eca Ri100
- Insulation material
Polyvinyl chloride
- Min. temperature range (flexible installation)
-5 °C
- Max. temperature range (flexible installation)
50 °C
- Min. temperature range (fixed installation)
-30 °C
- Max. temperature range (fixed installation)
70 °C
- Type
VER J-YY 4x2x0,6 Eca Ri100
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3336324 VER J-YY 4x2x0,6 Eca Ri100 Data cable J-YY 4 x 2 x 0.6 mm² Grey 100 m
Description
This installation cable is for telephone, measurement and signal purposes for fixed laying on or under plaster in dry and damp rooms.
This text is machine translated.
This text is machine translated.
Hints
Made in Europe
