Technical specifications
- With ground wire: Yes
- Product type
Power feed
- Cable type
NYIF-J
- No. of leads
3 x
- Cross section (each core)
1.50 mm²
- No. of leads (part 2)
3 x
- Cross section (each core) (part 2)
1.50 mm²
- Cross section
3 x 1.50 mm² + 3 x 1.50 mm²
- Cable features
Flat
Flexible
- Height
3.7 mm
- Content
50 m
- Nominal voltage
400 V
- Nominal voltage U0
220 V
- Packaged
Yes
- Sold per metre
No
- Manufacturer part #
VER NYIF-J 3x1,5 Fca Ri. 50
- Max. length sold by the metre
50 m
- Type
VER NYIF-J 3x1,5 Fca Ri. 50
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3335818 VER NYIF-J 3x1,5 Fca Ri. 50 Power feed NYIF-J 3 x 1.50 mm² 50 m
Description
Complies with VDE 0250. For the installation only in dry rooms as well in and under plaster. The cables must be covered with plaster throughout. Installation in cavities made of concrete, stone or non-flammable construction materials is permitted. The outer diameter indicates the width of the webbed cables. Height: 3.7 mm.
This text is machine translated.
This text is machine translated.
Hints
Made in Europe
Accessories
(*All information is plus legal VAT)The necessary accessories are required to use the article as described.
