Technical specifications
- Conductor material: Copper
- Conductor class: Fine strands
- Wire color: Black
- Low smoke in accordance with IEC 61034-2: Yes
- Product type
Wire core
- Cable type
SIAF
- No. of leads
1 x
- Cross section (each core)
1.50 mm²
- No. of leads (part 2)
1 x
- Cross section (each core) (part 2)
1.50 mm²
- Cross section
1 x 1.50 mm² + 1 x 1.50 mm²
- Cable features
Flat
Flexible
- Outside Ø
3.00 mm
- Factory colour
Black
- Content
100 m
- Nominal voltage
500 V
- Nominal voltage U0
300 V
- Packaged
Yes
- Manufacturer part #
VER SIAF 1,5 sw Ri.100
- Max. length sold by the metre
100 m
- Type
VER SIAF 1,5 sw Ri.100
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3335831 VER SIAF 1,5 sw Ri.100 Wire core SIAF 1 x 1.50 mm² Black 100 m
Description
Used at places where high temperature fluctuations make conventional PVC-insulated cables fragile or rough. The insulation is built on silicon-rubber basis. It is resistant to vegetable and animal fats, many oils and dilute acids as well as decomposition by alcohols, plasticizers, lyes and salt solutions. The insulation is tropical and resistant to oxygen and ozone. In case of fire, an insulating layer around the bare wires is created. Max. operating temperature: 180 °C
This text is machine translated.
This text is machine translated.
Hints
Made in Europe
