Technical specifications
- Conductor class: Fine strands
- Specification Wire insulation: Rubber - silicone rubber (SIR)
- With ground wire: No.
- Min Permitted bending radius, stationary use/fixed installation: 23 mm
- Specification of sheath material: Rubber - silicone RUBBER (SIR)
- Cable geometry: Round
- Min Permissible bending radius, flexible use/free movement: 31 mm
- Product type
Power feed
- Cable type
SIHF-OB
- No. of leads
2 x
- Cross section (each core)
1.50 mm²
- No. of leads (part 2)
2 x
- Cross section (each core) (part 2)
1.50 mm²
- Cross section
2 x 1.50 mm² + 2 x 1.50 mm²
- Cable features
Flat
Flexible
- Outside Ø
7.60 mm
- Content
50 m
- Nominal voltage
500 V
- Nominal voltage U0
300 V
- Packaged
Yes
- Manufacturer part #
VER SIHF-OB 2X 1,5 Ri. 50
- Insulation material
Silicone rubber
- Min. temperature range (fixed installation)
-60 °C
- Max. temperature range (fixed installation)
180 °C
- Max. length sold by the metre
50 m
- Type
VER SIHF-OB 2X 1,5 Ri. 50
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3337148 VER SIHF-OB 2X 1,5 Ri. 50 Power feed SIHF-OB 2 x 1.50 mm² 50 m
Description
Used at all places where cable insulation is exposed to high temperature fluctuations. Excellent weather resistance means they can be used at both high and low temperatures. Particularly suitable for use in power plants. Also in huts, steel and rolling mills, foundries, in aircraft construction and in shipbuilding as well as in cement, glass and ceramic factories, in headlights and high-performance lights and heaters of all kinds.
This text is machine translated.
This text is machine translated.
Hints
Made in Europe
Accessories
(*All information is plus legal VAT)The necessary accessories are required to use the article as described.
