Technical specifications
- Conductor material: Copper
- Conductor class: Single-wire
- Wire identification: Colour
- With ground wire: No.
- Side wire: No.
- Protective cover: Without
- Reinforcement/armoring: Without
- Jacket material: Polyvinyl chloride (PVC)
- Wire diameter 0.8 mm
- Min Permitted bending radius, stationary use/fixed installation: 38 mm
- Wire color: Various
- Product type
Power feed
- Cable type
YR
- No. of leads
4 x
- Cross section (each core)
0.80 mm²
- No. of leads (part 2)
4 x
- Cross section (each core) (part 2)
0.80 mm²
- Cross section
4 x 0.80 mm² + 4 x 0.80 mm²
- Cable features
Flat
Flexible
- Outside Ø
5.00 mm
- Factory colour
White
- Content
100 m
- Nominal voltage
100 V
- Packaged
Yes
- Sold per metre
No
- Manufacturer part #
VER YR 4x0,8 Ri.100
- Insulation material
Polyvinyl chloride
- Min. temperature range (flexible installation)
-5 °C
- Max. temperature range (flexible installation)
50 °C
- Min. temperature range (fixed installation)
-20 °C
- Max. temperature range (fixed installation)
70 °C
- Max. length sold by the metre
100 m
- Type
VER YR 4x0,8 Ri.100
- Shielded
No
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3336021 VER YR 4x0,8 Ri.100 Power feed YR 4 x 0.80 mm² White 100 m
Description
Structure according to VDE 0815. For the installation of bell systems Max. operating temperature: 70 °C
This text is machine translated.
This text is machine translated.
Hints
Made in Europe
