Image similar
Technical specifications
- Conductor class: Single-wire
- Wire identification: Colour
- Jacket material: Without
- Wire diameter 0.6 mm
- Number of rope elements: 1
- Wire rope element: Four-fold
- Shield over wire element: Without
- Wiring: Bundle
- Shield over stranding: Without
- Cable longitudinally watertight: No.
- Cable transverse water-proof: No.
- Protection jacket: Without
- Product type
Data cable
- Cable type
Yv
- No. of leads
4 x
- Cross section (each core)
0.6 mm
- No. of leads (part 2)
4 x
- Cross section
4 x 0.6 mm
- Outside Ø
1.20 mm
- Factory colour
Black
White
Green
Yellow
- Content
100 m
- Packaged
Yes
- Sold per metre
Yes
- Shielded
No
- Manufacturer part #
VER YV 4x0,6/1,1SwWsGnGeSp.100
- Insulation material
Polyvinyl chloride
- Min. temperature range (flexible installation)
-5 °C
- Max. temperature range (flexible installation)
50 °C
- Min. temperature range (fixed installation)
-30 °C
- Max. temperature range (fixed installation)
70 °C
- Max. length sold by the metre
100 m
- Type
VER YV 4x0,6/1,1SwWsGnGeSp.100
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3337565 VER YV 4x0,6/1,1SwWsGnGeSp.100 Data cable Yv Black, White, Green, Yellow 100 m
Description
As a connection cable in telecommunication systems and telecommunications equipment for the transmission of messages and telecommunications information.
This text is machine translated.
This text is machine translated.
Hints
Made in Europe
